BEA LO Linx 80.0240.04 Wiring Diagram

LO-LIN X GR EEN WH IT E YELLOW
SWIN G A C T . C OM . SA F .
BESAM 300 1 3 1 2 1 1
BESAM M /P 3 4 9
DOM YELLOW GREY BLUE
GT 300/400 BLACK RED WHITE
GT M AG 6 BLACK 5 RED 4 WHITE
HORTON 41 90 2 3, 6, 8 4
HUNTER ACT. RTN SAF. 1
KM K GREEN WHITE RED
STANLEY "L" ORANGE YELLOW RED
STANLEY M /P 2 1 , 8 7
STANLEY 521 TB4-5 TB4-4 TB4-8
TORM AX TDA 2 1 ,3, 6, 8 8 & 9
LO-LINX MOTOR HARNESS p/n: 20.5076
+
DC
RED
MOTOR
-
RED
SEE NOTE #1
EAGLE 1
LO-LINX EAGLE HARNESS p/n: 20.5096
EAGLE 2
SEE NOTE # 4
DOOR MTD SENSOR
APPROACH SIDE
NOTES:
1. MOTOR CONNECTION IS TIED IN PARALLEL TO EXISTING MOTOR LEADS. NO RESPECT TO PALARITY IS REQUIRED.
2. EXTERNAL SWITCHES ARE REQUIRED IF INHIBIT DESIRED AT SWING SIDE SUPERSCANS, SWITCH OPENS UPON INHIBIT POINT.
3. THE KNOWING ACT SWITCH IS CONNECTED AT THE AUX INPUT AND CAN BE ANY DRY CONTACT DEVICE SUCH AS A PUSHPLATE, CARD READER,
ETC. THE AUX INPUT IS REQUIRED FOR ALL INITIAL ACTIVATION WHEN FUNCTION 'FA' ON THE LO-LINX IS SET TO '01'.
4. THE SECOND BODYGUARD AND EAGLE ARE PRIMARILY USED IN DUAL-EGRESS APPLICATIONS.
IF AFTER TROUBLESHOOTING A PROBLEM, A SATISFACTORY SOLUTION CANNOT BE ACHIEVED, PLEASE CALL B.E.A., INC. FOR FURTHER ASSISTANCE
DURING EASTERN STANDARD TIME AT 1-800-523-2462 FROM 8AM - 5PM. FOR AFTER-HOURS, CALL EAST COAST: 1-866-836-1863 OR 1-800-407-4545 /
MID-WEST: 1-888-308-8843 / WEST COAST: 1-888-419-2564. DO NOT LEAVE ANY PROBLEM UNRESOLVED. IF YOU MUST WAIT FOR THE FOLLOWING
WORKDAY TO CALL B.E.A., LEAVE THE DOOR INOPERABLE UNTIL SATISFACTORY REPAIRS CAN BE MADE. NEVER SACRIFICE THE SAFE OPERATION
OF THE AUTOMATIC DOOR OR GATE FOR AN INCOMPLETE SOLUTION.WEB: WWW.BEASENSORS.COM
B LUE B R OWN
ST A LL ST A L C OM .
1 5, 1 7 1 6,1 8
5 1 3
PURPLE GREY
WHITE RED
3 VIOLET 5 RED
1 0 3, 6, 8
SAF. 2 RTN
YELLOW WHITE
BLUE YELLOW
7 1 , 8
TB4-1 0 TB4-9
7 1 , 3, 6, 8
DOOR MTD SENSOR
SAFETY SIDE
LO-LINX
MTR STALL SENSORS AUX
BEAM
TX
SEE NOTE #3
BODYGUARD (Y) HARNESS
USED FOR DUAL-EGRESS
APPLICATIONS
LO-LINX SUPERSCAN HARNESS
p/n: 70.5071
DOOR MTD SENSOR
APPROACH SIDE
BLACK
RED
SWITCH TO CTRL PWR SETUP
RX
LO-LINX SWITCH HARNESS p/n: 20.5078
LO-LINX CONTROL
HARNESS p/n: 20.5097
DOOR
CONTROL
BROWN
SEE NOTE # 4
WHITE
BLUE
YELLOW
GREEN
DOOR MTD SENSOR
SAFETY SIDE
100 ENTERPRISE DRIVE
PITTSBURGH, PA 15275
PHONE: (412) 249-4100
FAX:
EMAIL: www.beasensors.com
TITLE: GENERAL LO-LINX SYSTEM
DRAWN BY: REV BY:
SIZE:
JED TUC
SCALE: DATE:
A
NONE 10/15/2007
24 V
TRANSFORMER
Pre-wired
switch
assembly
AUTO
RED
BLACK
OFF
WHITE
HOLD OPEN
(412) 249-4101
PART NO:
80.0240.04
SHEET
1 OF 1
