Thermo Scientific signos RT Bladder Quick Start Manual

SEE FOR YOURSELF
G e t t i n g S t a r t e d
1
2
S c a n n i n g
3
4
For more infirmation please contact: AUInfo@thermofisher.com.au
Q U I C K S T A R T G U I D E
On/ Of f button
Press for 1 second to turn on or off
Green
The device is on
Flashing
Power Saving mode
Amber
Low battery
'Star t'
Begin scanning
'Star t + Pati ent'
Enter patient details before scanning
'Review'
Review previous scans
Position in g
The probe position is displayed in blue.
Help Button
Using the help button
will give more scanning instructions. will give more scanning instructions.
Use of Pr ob e
Apply Gel. Place the probe 1cm above the pubic
bone with silver orientation dots toward the
patients' right hand side.
Angle 10 degrees toward the patients' feet.
Scan from the bottom to the top of the bladder.
Federal (USA) law restricts
this device to sale by or on
the order of a physician
Refer to user manual before use.
?
