Bottom Covers - Chore-Time Turbo-Cool Installation Instructions Manual

Bottom Covers

Bottom Covers
Support Braces
Note: Install braces every
60"at every other pipe
hanger
Note:
4
1. Install Bottom Cover Plates with 1/4-20 hardware supplied.
2. Ribs of Bottom Cover to be coned up. Shown in Figure 9.
3. Center, Bottom Covers from bracket to bracket.
1
Put Support Braces together using 1/4-20 hardware. Be sure to adjust Support Braces
for proper height of system 36; 48-60-72.
The Support Braces are to be installed with self taping screws, (supplied with kit),
behind the splash plates and pipe hangers, as shown in Figure 10.
Lag bolt the bottom of the Support Brace to the trough mounting 2 x 6.
2
1
Figure 10. Close-up View of Support Brace Installation
All splash plates, end panels, and pipe hangers are to be fastened with
self tapping screws provided with the Stand Off Kit.
Turbo Cool Stand-Off Kit Installation Manual
2
1
Bottom Covers
1 Overlapped Bottom Covers
2 Bolt Overlapped pieces together
1609-5 6/99
Figure 9. Bottom Cover Installation
2
1
Support Brace Placement
1
2
1609-2 6/99
Part No.
43833
Part No.
Support Braces 43834
Pipe Hangers 43884
MV1609D
