OWNER'S MANUAL
CONTENTS:
Page 1 Specifications
2 Warning Information
3 Parts List
4-7 Assembly Instructions
8
Operating Instructions and Preventative Maintenance
9
Replacement Parts List
10
Warranty Information
PRESS SPECIFICATIONS
Sunex Part No.
Total Height
5712
61.5"
5720
64.5"
5720AH
64.5"
5712, 5720, 5720AH
Inside Width
Press Feet Length
20"
26"
24.5"
26"
24.5"
26"
5712 - 12 Ton Hydraulic Shop Press
5720 - 20 Ton Hydraulic Shop Press
5720AH - 20 Ton Air/Hydraulic Shop Press
Bed Width
Ram Stroke Pin Diameter
8.75"
5"
11.25"
5.125"
11.25"
5.125"
Press Plates Included
.75"
Y(2)
1"
Y(2)
1"
Y(2)
© Copyright 2018, Sunex Tools ®
rev. 10/03/18
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Sunex HD 5712
Summary of Contents for Sunex HD 5712
- Page 1 5712 - 12 Ton Hydraulic Shop Press 5720 - 20 Ton Hydraulic Shop Press 5720AH - 20 Ton Air/Hydraulic Shop Press OWNER'S MANUAL CONTENTS: Page 1 Specifications 2 Warning Information 3 Parts List 4-7 Assembly Instructions Operating Instructions and Preventative Maintenance...
- Page 2 Failure to read this manual completely and thoroughly, failure to understand its OPERATING INSTRUCTIONS, SAFETY WARNINGS, MAINTENANCE INSTRUCTIONS and comply with them, and failure to compy with the METHODS TO AVOID HAZARDOUS SITUATIONS could cause accidents resulting in serious or fatal personal injury and/or property damage. 5712, 5720, 5720AH rev. 10/03/18...
-
Page 3: Tools Needed
Press Plates - 2 Accessory only - Not needed for assembly Washers - 4 5712 - (2) 1" x 2" x 10" Plates 5720 - (2) 3/4" x 3" x 12" Plates 5720AH - (2) 3/4" x 3" x 12" Plates TOOLS NEEDED 5/16"-13 x 1"... - Page 4 5712 - 12 Ton Hydraulic Shop Press 5720 - 20 Ton Hydraulic Shop Press 5720AH - 20 Ton Air/Hydraulic Shop Press ASSEMBLY INSTRUCTIONS Note: In the upright position, inner bracing should form an inverted "v" with the narrower space facing the top of the press.
- Page 5 5712 - 12 Ton Hydraulic Shop Press 5720 - 20 Ton Hydraulic Shop Press 5720AH - 20 Ton Air/Hydraulic Shop Press ASSEMBLY INSTRUCTIONS CONTINUED Use bolts, washers and nuts to attach Z Bar to both sides of the press. Cross-section of press Note: Check all bolts for tightness.
- Page 6 5712 - 12 Ton Hydraulic Shop Press 5720 - 20 Ton Hydraulic Shop Press 5720AH - 20 Ton Air/Hydraulic Shop Press ASSEMBLY INSTRUCTIONS CONTINUED WARNING Pins must be COMPLETELY through BOTH SIDES of frame. t i n g i r...
- Page 7 5712 - 12 Ton Hydraulic Shop Press 5720 - 20 Ton Hydraulic Shop Press 5720AH - 20 Ton Air/Hydraulic Shop Press PUMP INSTRUCTIONS FOR 5712 & 5720 1. Place the handle on the release valve and 2. Place the pump handle in the cradle.
-
Page 8: Operating Instructions
5712 - 12 Ton Hydraulic Shop Press 5720 - 20 Ton Hydraulic Shop Press 5720AH - 20 Ton Air/Hydraulic Shop Press OPERATING INSTRUCTIONS This is the safety alert symbol used for the OPERATING INSTRUCTIONS section of this manual to alert you to potential personal injury hazards. - Page 9 5712 - 12 Ton Hydraulic Shop Press 5720 - 20 Ton Hydraulic Shop Press 5720AH - 20 Ton Air/Hydraulic Shop Press REPLACEMENT PARTS LIST ITEM NO. SUNEX PART NO. DESCRIPTION QTY. SCBP1214 i r p RS12FT Press Feet (5712) RS20FT Press Feet (5720 &...
- Page 10 5712 - 12 Ton Hydraulic Shop Press 5720 - 20 Ton Hydraulic Shop Press 5720AH - 20 Ton Air/Hydraulic Shop Press LIMITED WARRANTY SUNEX INTERNATIONAL, INC. WARRANTS TO ITS CUSTOMERS THAT THE COMPANY’S SUNEX TOOLS® BRANDED PRODUCTS ARE FREE FROM DEFECTS IN WORKMANSHIP AND MATERIALS.
