OWNER'S MANUAL
CONTENTS:
Page 1 Specifications
2 Warning Information
3 Assembly and Operating Instructions
4 Preventative Maintenance and Warranty Information
5 Exploded View Drawing and Parts List
5712BT
SPECIFICATIONS
Capacity .................................................................... 12 Tons
Height .........................................................................36-3/4"
Base Width .................................................................19-1/2"
Stroke .................................................................................. 6"
Shipping Wt.................................................................93 Lbs.
5712BT - 12 TON BENCH TOP
HYDRAULIC SHOP PRESS
1
