Custom Fireplace Program
Co-linear Direct Vent Gas Fireplaces
GALAXY SERIES - BAY
Installation and Operating Manual
Natural Gas & Propane
WARNING: If the information in these instructions are not followed exactly, a fire or explosion may result
causing property damage, personal injury or loss of life.
— Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other
appliance.
WHAT TO DO IF YOU SMELL GAS
—
•
Do not try to light any appliance.
•
Do not touch any electrical switch; do not use any phone in your building.
•
Immediately call your gas supplier from a neighbor's phone. Follow the gas supplier's instructions.
•
If you cannot reach your gas supplier, call the fire department.
— Installation and service must be performed by a qualified installer, service agency or the gas supplier.
Stellar Hearth Products
TM,
a division of Hearth & Home Technologies
Installer:
Leave this manual with the appliance.
Consumer: Retain this manual for future reference.
®
- 16873 Fish Point Rd SE, Prior Lake, MN 55372
Page 1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for stellar labs 4-BY-2-GL
Summary of Contents for stellar labs 4-BY-2-GL
- Page 1 www.stellarhearth.com Custom Fireplace Program Co-linear Direct Vent Gas Fireplaces GALAXY SERIES - BAY Installation and Operating Manual Natural Gas & Propane Installer: Leave this manual with the appliance. Consumer: Retain this manual for future reference. WARNING: If the information in these instructions are not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life. — Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
- Page 2 INS_GALAXY SERIES_BY REV C Page 2...
-
