Summary of Contents for GW Instek GDS-207
- Page 1 Compact Digital Storage Oscilloscope & Digital Multimeter GDS-200 & GDS-300 Series QUICK START GUIDE GW INSTEK PART NO. 82DS-22000MA1 ISO-9001 CERTIFIED MANUFACTURER...
- Page 2 This manual contains proprietary information, which is protected by copyright. All rights are reserved. No part of this manual may be photocopied, reproduced or translated to another language without prior written consent of Good Will Corporation. The information in this manual was correct at the time of printing.
-
Page 3: Afety Instructions
AFETY INSTRUCTIONS This section contains the basic safety symbols that may appear on the accompanying User Manual CD or on the instrument. For detailed safety instructions and precautions, please see the Safety Instructions chapter in the user manual CD. Safety Symbols These safety symbols may appear in the user manual or on the instrument. - Page 4 Power Cord for the United Kingdom When using the instrument in the United Kingdom, make sure the power cord meets the following safety instructions. NOTE: This lead/appliance must only be wired by competent persons. WARNING: THIS APPLIANCE MUST BE EARTHED IMPORTANT: The wires in this lead are coloured in accordance with the following code: Green/ Yellow: Earth...
-
Page 5: Etting Started
Series Lineup There are 6 models in the series, divided by DSO bandwidth, DSO memory depth and DMM digit resolution. Model Name Bandwidth Memory Temp. Depth Resolution Meas. 70MHz GDS-207 points 100MHz GDS-210 3½ 200MHz channel GDS-220 70MHz GDS-307 points... - Page 6 Simultaneous DMM and DSO • Features operation Portrait and landscape modes • Large 800 x 480 TFT panel and • capacitive touch panel 7.4V/6100mAH battery for up to 4 • hours operation Support for differential probes • Handy APPs - EE calculator, chip •...
- Page 7 Package Contents and Accessories Standard Accessories Item Part Number User Manual CD 82DS-2200E01 Quick Start Guide (this document) 82DS-22000M01 100MHz passive probe; for GDS- GTP-100A-4 207 /307, GDS-210 /310 200MHz passive probe; for GDS- GTP-200A-4 220 /320 Multimeter test lead x2 GTL-207 Soft carrying case (large) GSC-010...
- Page 8 Panel Overview 16.5pF 300V 300Vrms MAX. GDS-220 Digital Storage Oscilloscope 200 MHz 1GSa/s 600mA MAX CAT II 600V FUSED CAT III 300V 10A MAX FUSED Description Channel 1 BNC input 2. Channel 2 BNC input Tapped hole for 800 x 480 TFT screen, options cap.
- Page 9 Display Overview 18 19 20 21 Note: Background color has been inverted for clarity. Description Drop down menu Trigger frequency Trigger status Date and Time Memory bar Horizontal position Acquisition mode Trigger level Battery Indicator 10. Horizontal position indicator 11. Gesture control icon 12.
-
Page 10: Setting Up The Oscilloscope
Setting up the Oscilloscope This section describes how to set up the oscilloscope properly including setting the stand, power up and basic touch gestures. Power Up Before the unit is powered up for the first time, it is recommended that the unit is first fully charged. Plug the AC-DC power pack into the mains outlet. - Page 11 Tilting the Stand The GDS-200/300 has two adjustable tabs on the rear panel that can be used to position the instrument into two preset orientations. Horizontal Vertical Pull this catch Pull this catch Portrait and Landscape Mode Tap the top of the screen to access the Menu tray. Press the icon to toggle between horizontal and vertical view.
-
Page 12: Basic Operation
Basic Operation This section will go over all of the basic touch gestures that are available using the default settings. Please see the user manual for comprehensive explanations. Channel/Ref/Math Waveform Selection To select the active waveform, tap the desired channel, math or reference indicator. - Page 13 Vertical Scale Pinch in/out vertically to set the vertical scale of the selected waveform. Scale Indicator Vertical Scale Horizontal Position and Scale Swipe the screen horizontally to set the horizontal position of the displayed waveforms. Pinch in/out horizontally to set the horizontal scale of the display.
- Page 14 Trigger Source and Trigger Level Tap on the trigger level indicator to toggle between trigger sources. Swipe the screen to the right of the grid to set the trigger level with the currently selected source. Trigger Toggle trigger source Level Drop Down Menu The Drop Down menu contains the Menu tray and the App tray.
- Page 15 PECIFICATIONS The specifications apply when the oscilloscope is powered on for at least 30 minutes under +20°C-+30°C. Scope Specifications Vertical 2 (BNC-Shield) Channel 1MΩ Input Impedance CATII 300VRMs Maximum Input AC, DC, GND Input Coupling DC-70/100/200MHz (-3dB) Bandwidth <5ns / 3.5ns / 1.75ns approx. Rise Time 2mV/div-10V/div (1-2-5 Sensitivity...
- Page 16 Trigger Ch1 or Ch2 Source Auto, Normal, Single, Force Trigger Mode Edge, Pulse width, Video, Trigger Type Alternative 10ns - 10s Trigger Holdoff AC, DC, LFR, HFR, NR Coupling DC - 25MHz: approx. 0.5div or Sensitivity 25MHz - 70/100/200MHz: approx. 1.5div or 15mV Horizontal 5ns-100s/Div (1-2-5 Range...
- Page 17 Miscellaneous Available Multi-language Menu Available On-line Help Available Time and Clock Battery Li-polymer 6100mA/hr, 7.4V Battery Power (Built-in) 2.0 hour (75%) Charge Time 4.1 hours, depending on the Operation Time operating conditions. Interface USB Device (Isolated) 120MB Internal Flash Disk Display 7 Inch Type...
- Page 18 DMM Specifications Basic 50,000 counts, 4½ digits (GDS- Reading 307/310/320) 3½ digits (GDS-207/210/220) CAT II 600VRMS, CAT III Voltage Input 300VRMS DC Voltage 50mV, 500mV, 5V, 50V, 500V, Range 1000V, 6 ranges GDS-307/310/320: 50mV, Accuracy 500mV, 5V, 50V, 500V ±(0.05% + 5 digits), 1000V ±(0.1% + 5...
- Page 19 AC Current* 50mA, 500mA, 10A 3 ranges Range 50mA, 500mA, ±(1.5% + 15 Accuracy digits) at 50Hz-1kHz; 10A ±(3% + 15 digits) at 50Hz - 1kHz * Measure range: >10mA Resistance* 500Ω, 5kΩ, 50kΩ, 500kΩ, 5MΩ, Range 5 range 500Ω, 5kΩ, 50kΩ, 500kΩ ±(0.3% Accuracy + 3 digits);...
-
Page 20: Ec Declaration Of Conformity
GOOD WILL INSTRUMENT (SUZHOU) CO., LTD. No. 69, Lushan Road, Suzhou New District Jiangsu, China declares that the below mentioned product GDS-207, GDS-210, GDS-220, GDS-307, GDS-310, GDS-320 Are herewith confirmed to comply with the requirements set out in the Council Directive on the Approximation of the Law...
