- Page 1 User Manual EKI-1751PI Series Long Reach PoE Extenders...
- Page 2 No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. Information provided in this manual is intended to be accurate and reliable. How- ever, Advantech Co., Ltd.
- Page 3 Technical Support and Assistance Visit the Advantech web site at www.advantech.com/support where you can find the latest information about the product. Contact your distributor, sales representative, or Advantech's customer service center for technical support if you need additional assistance.
- Page 4 Warnings, Cautions and Notes Warning! Warnings indicate conditions, which if not observed, can cause personal injury! Caution! Cautions are included to help you avoid damaging hardware or losing data. e.g. There is a danger of a new battery exploding if it is incorrectly installed. Do not attempt to recharge, force open, or heat the battery.
- Page 5 Safety Instructions Read these safety instructions carefully. Keep this User Manual for later reference. Disconnect this equipment from any DC outlet before cleaning. Use a damp cloth. Do not use liquid or spray detergents for cleaning. For plug-in equipment, the power outlet socket must be located near the equip- ment and must be easily accessible.
- Page 6 Der arbeitsplatzbezogene Schalldruckpegel nach DIN 45 635 Teil 1000 beträgt 70dB(A) oder weiger. Haftungsausschluss: Die Bedienungsanleitungen wurden entsprechend der IEC-704-1 erstellt. Advantech lehnt jegliche Verantwortung für die Richtigkeit der in diesem Zusammenhang getätigten Aussagen ab. EKI-1751PI Series User Manual...
- Page 7 Safety Precaution - Static Electricity Static electricity can cause bodily harm or damage electronic devices. To avoid dam- age, keep static-sensitive devices in the static-protective packaging until the installa- tion period. The following guidelines are also recommended: Wear a grounded wrist or ankle strap and use gloves to prevent direct contact to the device before servicing the device.
-
Page 8: Table Of Contents
Contents Chapter Product Introduction ......1 Description ....................2 Features ....................2 Specifications .................... 2 Applications....................3 Reference Performance Data ..............4 1.5.1 24AWG Copper Wire ..............4 1.5.2 Coaxial Cable................4 Chapter Hardware Description ......5 Applications....................6 Product Outlook ..................6 Installation Accessory ................ - Page 9 List of Figures Figure 1.1 Remote Power Enable ....................3 Figure 1.2 Remote Power Disable....................3 Figure 2.1 EKI-1751PI-M-AE Faceplate ..................6 Figure 2.2 EKI-1751PI-R-AE Faceplate ..................6 Figure 2.3 Installation Accessory....................7 Figure 3.1 Installation Accessory....................10 EKI-1751PI Series User Manual...
-
Page 10: Chapter 1 Product Introduction
Chapter Product Introduction... -
Page 11: Description
100 meters for the network infrastructure. The solution works in pairs for point to point connectivity. It features EKI-1751PI-M-AE Long Reach PoE Extender that the master unit is at the central site and on the receiving end is EKI-1751PI-R-AE Long Reach PoE Extender with 4 PoE (PSE) ports. -
Page 12: Applications
Power Supply Terminal blocks for redundant DC power inputs Input Voltage: 48 to 57 V Power Consumption: – EKI-1751PI-M-AE: 65 Watts maximum – EKI-1751PI-R-AE: 125 Watts maximum Over current protection Automatic short protection Protocol Support Transparent bridging to higher layer protocols ... -
Page 13: Reference Performance Data
Reference Performance Data 1.5.1 24AWG Copper Wire Profile Asymmetrical Symmetrical Distance Upstream Downstream Upstream Downstream PoE Output Line Rate Line Rate Line Rate Line Rate Power (Mbps) (Mbps) (Mbps) (Mbps) 300 m 30 W 400 m 20 W 600 m 15 W 800 m 1,000 m... -
Page 14: Chapter 2 Hardware Description
Chapter Hardware Description... -
Page 15: Applications
Applications EKI-1751PI Series are Long Reach PoE Extenders with four 10/100Base-TX IEEE 802.3at PoE Ports. This chapter shows the product outlook and Hardware interfaces. Product Outlook Figure 2.1 EKI-1751PI-M-AE Faceplate Figure 2.2 EKI-1751PI-R-AE Faceplate EKI-1751PI Series User Manual... -
Page 16: Installation Accessory
Installation Accessory Figure 2.3 Installation Accessory EKI-1751PI Series User Manual... -
Page 17: Chapter 3 Led Definition
Chapter LED Definition... -
Page 18: Led Indicators
LED indicators The LED indicators could provide instant feedback to users; the behaviors of the LED are given in below table: LED Name Color Indicator Condition Local Power Green No local power input Local power received Remote Power Green No power is transmitted over Line Power is transmitted over Line 4 x PoE Green... -
Page 19: Led Display Status
LED Display Status According to your operation environment and power allocation, the display status of PoE Output LED will have three situations for EKI-1751PI-R-AE device. When the PoE power voltage is above or equal 50V (>=50V), the PoE output is normally working and LED display is stable status. - Page 20 Chapter Power...
-
Page 21: Chapter 4 Power
48 V to 57 V , terminal Block. Output: – EKI-1751PI-M-AE: Provide power output to Line (Remote Power Feeding) to support remote power. – EKI-1751PI-R-AE: Ethernet port provide 4-port PoE PSE function to 802.3at (30W). Power Consumption: –... -
Page 22: 3-Position Dip Switch
Chapter 3-Position DIP Switch... -
Page 23: 3-Position Dip Switch
3-Position DIP Switch Proscend EKI-1751PI Series are equipped with DIP Switch selection, which can allow users to select the parameters in order to meet the needs of different applica- tions. The parameter options should be set identically on EKI-1751PI Series. Option Profile Remote Power... - Page 24 No part of this publication may be reproduced in any form or by any means, electronic, photocopying, recording or otherwise, without prior written permis- sion of the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2018...
