Technical Specification

Power consumption:
-
~190mA on the +12Volt Rail
-
~32mA on the -12 Volt Rail
-
+5 Volt Rail is not connected
Hardware:
-
Colour Graphics IPS display with a resolution of 480 x 320 pixels
-
10 full size and 6 half size buttons
-
28 mini-Jack (mono), 4 CV Inputs (range 0..10 Volt) , Clock+Reset Inputs(5 Volt), 12 CV
outputs (Range -5 Volt /+5 Volt or 0 Volt / +10 Volt), 6 Trigger/Gate Outputs (5 Volt),
2 Sample outputs (-5 Volt/+5 Volt), Clock + Reset Output (5 Volt)
-
2 toggle switches to change the offset of the CV voltages
-
2 LED to indicate clocks
-
microSD connector accessible on frontpanel
-
10 pin boxed bus connector (power)
-
Expander connector (12 pin boxed) for IO-Expander (Midi In/Out + Sega Gamepad
connector) (Expander must be ordered seperately)
-
Expander connector (14 pin boxed) for special Nerdseq extensions like a NSA (Nerd
Sound Adapter) which are dedicated Cartridges including full synthesizers. Those are totally
integrated in the Nerdseq sequencer. (Under development)
Tracker:
-
6 CV/Trigger/Gate tracks for 12 CV and 6 Trigger/Gate outputs
-
2x2 sample tracks for 2 sample outputs (mono)
-
239 Sequencer rows
-
175 Patterns with each 64 (and less) Steps
-
176 Patches
-
32 Tables with 16 (and less) steps
-
16 Automation slots (2do)
-
12 Sample slots
Nerdseq – a tracker based Eurorack sequencer
User Manual Revision V0.9.9 for Firmware V1.13
Page 5
27 February 2018
