Honda 08P00-TK8-100B Installation Instructions Manual

Splash guards.
Hide thumbs


Advertisement

INSTALLATION
INSTRUCTIONS
PARTS LIST
Left front splash guard
Right front splash guard
Left rear splash guard
Right rear splash guard
4
Self-tapping screws, 5 x 25 mm
TOOLS AND SUPPLIES REQUIRED
Phillips screwdriver
Stubby Phillips screwdriver
Pushpin
Ratchet
10 mm Socket
© 2013 American Honda Motor Co., Inc. – All Rights Reserved.
Accessory
SPLASH GUARDS
P/N 08P00-TK8-100B
Illustration of the Splash Guards Installed on the
Vehicle
INSTALLATION
Customer Information: The information in this
installation instruction is intended for use only by skilled
technicians who have the proper tools, equipment, and
training to correctly and safely add equipment to your
vehicle. These procedures should not be attempted by
"do-it-yourselfers."
NOTE:
• Do not damage the body paint finish.
• Clean and wax the areas to be covered with a high
quality paste wax.
Note:
The 4 new screws will be taped to the
inside of 1 or 2 of the splash guards
in very small plastic bags.
AII 49542 (1306)
Application
2014 ODYSSEY
RIGHT REAR
SPLASH GUARD
RIGHT FRONT
SPLASH GUARD
LEFT FRONT
SPLASH GUARD
Publications No.
AII 49542
Issue Date
JUNE 2013
LEFT REAR
SPLASH GUARD
QC11402AY
1 of 3
08P00-TK8-1A00-90
