2. On the Zones Setup page, enter values for the parameters indicated in
Web Page Item
Device Name
Beep Before Page
Bypass DTMF
Enable
Zones 1-4 Checkboxes
Group Name
RTFM Announce
3. After changing the parameters, click Save Settings.
VoIP Zone Controller 4-Port Audio Out Operations Guide 930109C
Table 2-5. Zones Setup Parameters
Description
Shows the name of the device.
Check this box to play a beep before a page is sent.
Check this box to send a page without having to enter a two-
digit tone. When enabled, all four zones will be paged without
waiting for DTMF entry.
Check this box to enable the Group.
Check the box for the Zones that should comprise this Group.
Assign an identifier to the Group.
Check the box for the Zone that you want to hear a RTFM
announcement from.
Click on this button to save your configuration settings.
Changing a parameter that has an asterisk next to it will cause
a system reboot when saved.
Link to the Network Setup web page.
Link to the Admin Settings web page.
Link to the SIP Setup web page.
Link to the Upgrade Firmware web page.
Link to the Home page.
Implementing the VoIP Zone Controller
Set up the Zones
Table 2-5.
