Ampac EV3000 4210-0030 Installation Manual

ADVANCED WARNING
SY ST EMS
General:
The Visual Output Board (EV3000) Fast Fit Kit consists
of:
1 x Visual Output Board
4 x 4K7 EOL (RES1096) LED STROBES
4 x 10K EOL (RES1010) XENON STROBES
1 x 26 Way Ribbon Cable 1280mm (260-0029)
4 x M3 x 6mm screws (HW1585)
4 x M3 Rivnut (HW2323)
4 x M3 x 8mm Spacer (HW2274)
Description:
The BRDEV3VOB3-A / BRDEV3VOB3-B or the 302-
623B / 302-623C cater for field connections of Visual
Warning Strobes. Each board will terminate four (4)
zones of Visual Warning Strobes.
Each Zone Output on a BRDEV3VOB3-A / 302-623C
board can cater for up to four pairs of LED strobes.
Each Zone Output on a BRDEV3VOB3-B / 302-623B
board can cater for up to forty pairs of XENON strobes.
NOTE: XENON strobes and LED strobes can not be
inter-changed. Use the
configuring your system.
BRDEV3VOB3-A = LED STROBES
302-623C = LED STROBES
BRDEV3VOB3-B = XENON STROBES
302-623B = XENON STROBES
Installation:
Mount Board on appropriate standoffs and fit to rear
backpan using existing mounting points if available.
Visual Warning Strobes must be capable of operating
on 24V DC (nominal). See approved Visual Warning
Strobes.
If no Visual Warning Strobes are fitted to an output,
terminate with 10K EOL for XENON STROBES or 4K7
EOL for LED STOBES. Otherwise terminate the last
Visual on a line with the correct EOL (see Figures 3 and
4 )
Each visual output from the EV3000 will operate a pair
of indicators, i.e. an Alert (Amber) and Evac (Red)
Strobe. Visual pairs are fitted in reverse polarity.
MAN2983-1
WORLD LEADER OF INNOVATIVE SOLUTIONS IN FIRE DETECTION AND ALARM SYSTEMS
Ampac Technologies Australia Tel: +61 8 9201 6100 Europe Tel: +44 (0) 1302 833 522 New Zealand Tel: +64 9 443 8072 www.ampac.net
EV3000 Visual Output Board
Installation Guide
appropriate board when
Item Numbers: 4210-0030 (XENON)
Observe anti-static precautions at all times
Connections
Field Use
Connections
TB1 - 1, 2 Output Pair Zone 1
TB2 - 1, 2 Output Pair Zone 2
TB3 - 1, 2 Output Pair Zone 3
TB4 - 1, 2 Output Pair Zone 4
Factory Use
Connections
TB5-1,2 +24V
TB5-1,2 0V
CN1 Control Cable to 302 4220 board.
CN2 Control Cable to next 302-623B/C
board or BRDEV3VOB3-A/B
Fuse Ratings:
BRDEV3VOB3-A/B
Fuse Use
F1-4 +24V Output 1
302-623B/C
F1-4 +24V Output 3
NOTE: Circuit to Visual Strobes are polarised refer to
Figures 3 and 4 for more detail.
Approved Visual Warning Strobes:
Item Description
Number
208-0011 24v Xenon Strobe
Combined Red/Amber
208-0060 SONOS LED Strobe Red
208-0061 SONOS LED Strobe Amber
208-0062 SONOS LED Strobe Clear Lens
208-0063 SONOS LED Strobe
Combined Red/Amber (Flush Mount)
208-0064 SONOS LED Strobe Deep Base IP65
208-0065 SONOS LED Strobe
Combined Red/Amber IP65
208-0066 SONOS LED Strobe
Combined Red/Amber (Surface Mount)
N1236
4210-0031 (LED)
Rating
3 amp M0205
3 amp 3AG
Page 1
