- Page 1 SMC RANGE O P E R A T I N G I N S T R U C T I O N S...
- Page 2 POST EQ FAST TRACK GUIDE For those familiar with TRACE ELLIOT graphic preamplifiers here is a quick run through the facilities to get you plugged in and playing as soon as possible. With the correct mains power connected to the mains inlet of your amplifier, and your choice of speaker or speakers connected to the speaker output sockets, turn on the power to the unit with the rear panel power switch.
- Page 3 FULL OPERATING INSTRUCTIONS Input Sockets There are two INPUT sockets, one for PASSIVE instruments i.e. those that have no internal preamp or battery and one for ACTIVE instruments. The PASSIVE socket has a very high input impedance to perfectly match the output signal from a passive instrument.
- Page 4 N.B. Playing PASSIVE basses with the instruments own volume control turned back will reduce the upper frequency response of the instrument, so try to keep this control well advanced, using the amplifiers OUTPUT LEVEL control to provide for larger changes in volume.
- Page 5 If you have used any full range compression then you will know what we mean. That was before the TRACE ELLIOT SMX series of amplifiers where we developed a compressor in which the bass signal is split into its HIGH and LOW frequency components, and each passes through its own compressor, one optimized for LOW frequencies and one optimized for HIGH frequencies.
- Page 6 This principle has been used in the SMC series of amplifiers i.e. two compressors are used, however the controls for these two compressors have now been simplified to one rotary control that adjusts the compression level for both the HIGH and LOW frequency compressors simultaneously.
- Page 7 Balanced DI A balanced DI output is provided on the SMC preamp for direct connection to a balanced ‘Mic’ input on a mixing desk. This may be used for either Direct Injection of the bass into a PA system or for recording purposes. The balanced DI is provided on a standard Male XLR socket located on the front panel.
- Page 8 230 V - T3.15 A MAINS INPUT 260V A 115V @ 2.2 A MANUFACTURED IN ENGLAND BY:- TRACE ELLIOT LTD BACK PANEL FACILITIES Mains Inlet Socket For connection to your countries mains supply. Ensure that the amplifier has the correct voltage marked on the back for your country prior to connecting the mains power cable to the supply.
- Page 9 SMC SERIES PREAMP SPECIFICATIONS Inputs Passive Bass Input Impedance 2 MΩ Signal Range 50mV to 10V peak to peak Active Bass Input Impedance 100kΩ Signal Range 100mV to 20V peak to peak Effects Return Impedance 22kΩ Signal Level -10dBv Outputs Effects Send Impedance 22kΩ...
- Page 10 électromagnétiques ou en émettent les enceintes de haut-parleur Trace Elllot ne devraient emit or be affected by electro magnetic fields. Trace Elliot loudspeaker enclosures should not be pas étre utilisées à moins de 2 mètres de l’équipement susceptible d’être affecté par les parasites used less than 2 metres away from equipment which is likely to be affected by electro magnetic électromagnétiques.
- Page 11 Alle høyttalere og pick–up'er til gitarer gir nødvendigvis fra seg eller påvirkes av röd färg. elektromagnetiske felter. Trace Elliot–høyttalerkabinetter må ikke brukes mindre enn 2 m fra utstyr Om en A 13 amp (BS1363) stickpropp används måste en 13 amp säkring användas eller om som trolig kan påvirkes av elektromagnetisk støy.
- Page 12 áhrifum af rafsegulsviom. Trace Elliot hátalarakerfi ætti ekki ao nota í innan vio 2 metra fjarlægo frá tækjum, EMC advarsel sem kynnu ao veroa fyrir áhrifum rafsegultruflana.
- Page 13 πρε ´πει να εκπε ´ µπουν η ´ να επηρεα ´ζονται απο ´ τα ηλεκτροµαγνητικα ´ πεδι ´ α. Τα εσω ´κλειστα µελαϕω ´νου της TRACE ELLIOT να µην χρησιµοποιου ´νται λιγο ´τερο απ ´ο 2 µε ´ τρα µακρια ´ απο ´ τη συσκευη ´ που πιθανο ´ν να επηρεα ´ζονταιι απο ´ ηλεκτροµαγνητικη ´...
