- Page 1 Trace Elliot® Elf Bass Instrument Amplifier Owner’s Manual...
- Page 2 • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. CAN ICES-3(B)/NMB/3(B) Trace Elliot • Hwy. 5022 Hwy. 493 North • Meridian, MS 39305 Tel: (601) 486-2255 • Fax: (601) 486-1156 • www.traceelliot.us...
- Page 3 The Trace Elliot Elf packs all of the 200W of crystal-clear bass tone you would expect from our amplifiers in a miniscule package, that can easily fit into a pocket! This amp sounds clean and refined, but if you push it, it will overdrive naturally, for a smooth and musical sound.
- Page 4 (1) INPUT socket This is to connect the 1/4” jack lead from your instrument. Alternatively, if any effect units are being used before the amplifier then the output from the last unit is connected here. Experience has shown us that not all 1/4” jack plugs are made equal, therefore, we recommend the use of only high quality 1/4”...
- Page 5 Also, please use only cabinets built with professional-quality bass guitar musical instrument loudspeakers. Be aware that the protection circuitry within the ELF will detect overexcursion events caused by inferior speakers and guitar speakers, which are not meant for bass. The protection circuits will react to these events by momentarily interrupting the sound.
- Page 6 Specifications noise floor = -104.3dBu Mains Voltage: noise floor w/sig (nom.) = -88dBu 100-120 vac - 50/60Hz - T3.15AL/250V 230 vac - 50/60Hz - T1.6AL/250V Weight: Power Consumption: 1.6 lb (0.73 Kg) Typical = 30W Maximum = 240W Dimensions (H x W x D): SMPS: 1.35”...
- Page 7 Warranty registration and information for U.S. customers available online at www.traceelliot.com/warranty or use the QR tag below...
- Page 8 Features and specifications are subject to change without notice. Trace Elliot • Hwy. 5022 Hwy. 493 North • Meridian, MS 39305 Tel: (601) 486-2255 • Fax: (601) 486-1156 • www.traceelliot.us ©2010 Printed in U.S.A. 80305734...
