System Setup

HDMI

Under the HDMI setting CEC and ARC can be
switched on/off.
Consumer Electronics Control (CEC) is an
HDMI feature which allows one device to be
controlled from another device. If the MSU is
connected to a TV which supports CEC then
volume control can be controlled from the
television. Turning on and off the television
will also turn on/off the MSU depending on
the settings on the television.
Audio Return Channel (ARC) is an HDMI
feature which allows audio to be sent back
from the TV to the MSU through the HDMI
output cable from the MSU. When the MSU
is connected to a TV with ARC through an
HDMI cable the video signal are send to the
TV. When watching TV the audio signal is
send back through the same HDMI cable to
the MSU so the TV sound is played through
the MSU instead. This way only one cable is
needed between MSU and TV.

Power Auto

This controls how the MSU works when no input signal is detected. The MSU can be set to shut
down after 30 or 60 minutes of inactivity. Chose 'Never' if you do not want the MSU to shut down
unless you do it yourself.
Setting the MSU to 'Sleep' means that the MSU will enter a sleep mode when pressing the turn off
button on either the MSU or remote control. 'Sleep' mode means that the display and amplifier
shuts down to minimise power consumption when not used but the WiFi network connection is
on. This allows the MSU to be turned on from the MSU iPhone App.

Volume Level

This sets the volume level when the MSU starts up. It can either be set to Last or Custom. When
Last is chosen the volume level at last shutdown will be used when turning on again.
Custom is used to manual chose the start-up volume level in the range 10 to 99.

WiFi Module 2.4GHz

The MSU can connect to WiFi networks or create its own when needed. When choosing 'Direct'
the MSU will create its own network which devices can connect and stream to without use of
Sleep
HDMI
Power Auto
System
Setup
Volume
Level
WiFi Module
System
Reset
OFF/ON
CEC OFF/ON
ARC OFF/ON
30 min
60 min
Never
Last
Custom 10dB - 99dB
Direct
WPS
Connect
Login Share
OK?
