Summary of Contents for Aztec Tents Tidewater Sailcloth Tents

  • Page 2: Important Safety Information

    The installation of electrical, plumbing, lighting, appliances and/or HVAC equipment are not covered within this manu- al. Users/Installers shall follow local code requirements for the installation of these items using certified personnel. Aztec Tents shall be indemnified and held harmless from any such use or injury resulting from its use. ***IMPORTANT SAFETY INFORMATION*** Proper personnel safety equipment should be worn at all times during the installation of any tenting products.

  • Page 3: Parts List

    Thank you for your recent purchase from Aztec Tents. The following procedures will help you through your installation. If you ever run into problems with the installation of your Aztec Tent , please call one of our sales/service professionals. A complete listing of sales, service, and operational support is always available on our website at www.aztectents.com.
  • Page 4 Fabric Care & Warnings The sailcloth fabric developed for the Tidewater system requires specific attention during installation, cleaning, and stor- age to maintain its maximum life span. Unlike conventional tent fabrics, the sailcloth used in the Tidewater system is significantly lighter in weight and significantly more translucent than other tent fabrics. Please follow the following care and maintenance guidelines provided for this product.
  • Page 5 THIS PAGE INTENTIONALLY LEFT BLANK www.aztectents.com...
  • Page 6 Installation- Step 1: Layout and mark the terminating points for the legs, center- poles, and anchoring. Anchoring points shall be placed at a dis- tance equal to twelve (12”) inches less than the leg height and in line of pull that falls directly in line with the corresponding center pole and corresponding leg.
  • Page 7 Step 5: Assemble and erect the center pole(s). From underneath the tent insert the tip (pin) of the centerpole through the ring at the peak and push the fabric toward the sky until the centerpole is vertical and the bottom of the pole is positioned on the mark made in Step 1.
  • Page 8 www.aztectents.com...
  • Page 9 www.aztectents.com...
  • Page 10 www.aztectents.com...
  • Page 11 www.aztectents.com...
  • Page 12 www.aztectents.com...
  • Page 13 www.aztectents.com...
  • Page 14 www.aztectents.com...
  • Page 15 www.aztectents.com...
  • Page 16 www.aztectents.com...
  • Page 17 www.aztectents.com...
  • Page 18 www.aztectents.com...
  • Page 19 www.aztectents.com...
  • Page 20 www.aztectents.com...
  • Page 21 www.aztectents.com...
  • Page 22 www.aztectents.com...
  • Page 23 www.aztectents.com...
  • Page 24 www.aztectents.com...
  • Page 25 www.aztectents.com...
  • Page 26 www.aztectents.com...
  • Page 27 www.aztectents.com...
  • Page 28 www.aztectents.com...
  • Page 29 www.aztectents.com...
  • Page 30 www.aztectents.com...
  • Page 31 www.aztectents.com...
  • Page 32 www.aztectents.com...
  • Page 33 www.aztectents.com...
  • Page 34 Tidewater Squaring: Squaring Jig Version Step 1: The Squaring Diagram (Example 44’x83’) Step 2: With 2 tape measures, establish the interior box, square with diagonal measurement establishing the four corner side pole positions. For this example we’ll designate the two corner side poles on the left side of the drawing as SP-A and SP-B Step 3: Layout your Tidewater Squaring Jig so that the Side...
  • Page 35 Step 4: Hold the Center Pole ring in place and move the squaring jig so that the Side Pole Marker 3 ring is positioned over the mark at SP-B. With the Center Pole Ring and Side Pole Marker 3 ring firmly secured, pull on the Side Pole Marker 2 ring to trian- gulate the next side pole position.
  • Page 36 Tidewater Squaring: Tape Measure Version Step 1: The Squaring Diagram (Example 44’x83’) Step 2: Establish the interior box, square with diagonal measurement. Step 3: Mark the center pole locations. The center poles are located 1/2 the distance of the width of the tent.(In this example the width is 44’ 11 1/4”...
  • Page 37 Step 4: Triangulate the “round end” side pole locations. The distance from the center pole to each side pole on the “round end” is constant. (On the 44x83 example shown, the distance is 22’ 5 5/8”) Anchor the end of one tape measure at “CP” and the end of a second tape measure at “A”...
  • Page 38 Parts Listing Item No. Weight lbs Item Z33520X01701 20x17 Tidewater Sail Tent-Wht Z33520X02701 20x27 Tidewater Sail Tent-Wht Z33520X03701 20x37 Tidewater Sail Tent-Wht Z33532X03001 32x30 Tidewater Sail Tent- Wht Z33532X04001 32x40 Tidewater Sail Tent-Wht 32x50 Tidewater Sail Tent-Wht Z33532X05001 Z33532X06001 32x60 Tidewater Sail Tent-Wht Z33544X04301 44x43 Tidewater Sail Tent-Wht Z33544X06301...
