Package contents Carefully unpack your box and take out the items listed below. If any of the items are missing or damaged, please contact your dealer immediately: ¥ One Chromebook ¥ One AC adapter ¥ One warranty card ¥ This quick guide 1
...
Page 3
Layout Name Name Microphone USB 2.0 port Webcam Micro SD card slot LCD monitor Touchpad Audio combo jack 2
...
Page 4
Name Name DC input jack HDMI port USB 2.0 port Speaker 3
...
Function keys Icon Description Icon Description Increase screen Previous page brightness Next page Mute Reload current Decrease audio page volume Full-screen mode Increase the volume Switch to next Search window Decrease screen brightness 4
...
Page 6
Before powering on for the first time Charge the battery with the adapter coming with your l Chromebook until the charging indicator turns from red to green. Make sure there is a wireless network available for l you to connect your Chromebook. Note: If the only available network is a wired one, you need to acquire separately a USB internet adapter that supports Linux systems.)
Getting started Step1: Turn on your Chromebook for the first time Press the power button. For the first time you power on your Chromebook, a dialog will appear as shown below. Step.2: Select your language settings If there is more than one way to type in your language, 6
...
Page 8
you may be prompted to select a keyboard input method as well. Step3: Connect to a network Select a wireless network from the "Select a network" list to connect to the Internet. If your selected network is a protected one, you will be prompted to enter your password to connect to it.
Page 9
Step 5: Create your Google Account Note: The first account signed in here will be set as the owner account and is the only account that will be allowed to change Chrome settings. When you reach this step, the dialog shown below will ...
Page 10
Step 6: Set your account picture You can use the Chromebook’s built-in webcam to take a photo of yourself, or just choose an icon instead and change it later. The desktop will be open as shown below, and you can start using your Chromebook.
Specifications Rockchip RK3288 Cotex-A17 Processor Quad Core DDR3L type Memory 2G/4G (depending on model) eMMC for V4.51&V5.0 Storage AW-CM195NF Combo Module BCM43540, 802.11 Wireless a/b/g/n/ac ,2x2, 2.4G and 5.0G Bluetooth M.2 Combo module EDP 1366x768 TN Display 11.6" TN for EDP interface Webcam 1.3M HD Polymer Battery...
Page 12
l 1 x 12V DC IN l 1 x 3.5mm combo Jack Input/Output l 1 x HDMI (A-TYPE) l 2x USB2.0 (Black) l 1xTF slot (Micro SD) Speaker & l 2 x Build-in speakers (Stereo) l 1 x Internal MIC l...
Page 14
WWW.CTL.NET A U.S. Company. Beaverton, OR, USA...
