GENERAL PUMP

FEATURES

• Triplex plunger pump
• New Forged brass manifold , increases
working pressure to 4,000 PSI
• New plunger guide bushing
(patent pending)
• Solid ceramic plungers with dual guide
system
• New dual diameter plunger guide
• New optimized outlet valves
• New dual lip oil seal
• 1" Hollow shaft, flanged for direct couple
to gas engines (SAE J609B)

SPECIFICATIONS

Pump Model
EP1506G8 EP1508G8
Maximum Volume
2.9 GPM
Maximum Discharge
3,045 PSI
Pressure
Horsepower
6.0 HP
Maximum Pump
Speed
Maximum Inlet
Pressure
Max. Inlet Vacuum
Plunger Bore
Plunger Stroke
.236 in./6 mm .315 in./8 mm .354 in./9 mm .394 in./10 mm .236 in./6 mm .315 in./8 mm
Oil Capacity
Maximum Fluid
Temperature
Inlet Port Thread
Discharge Port
Thread
Shaft Diameter
Weight
Dimensions
General Pump
is a member of
the Interpump Group
A member of the Interpump Group
Triplex Plunger Pump, 1" Hollow Shaft
EP1509G8 EP1510G8
3.4 GPM 3.7 GPM 4.2 GPM
3,000 PSI
7.1 HP 7.6 HP 8.7 HP
.591 in/15 mm
Ref 300922 Rev.A
EP1306G8 EP1308G8 EP1309G8
2.1 GPM 2.6 GPM 2.9 GPM
5.7 HP 7.1 HP 7.9 HP
3400 RPM
125 PSI
Flooded
.512 in./13 mm
.354 in./9 mm .394 in./10 mm .433 in./11 mm
15 oz.
o
165 F
1/2"-14 BSP-F
3/8"-19 BSP-F
.945 in./24 mm
15.4 lbs.
9.5"x9.5"x6.45"
02-13
EP Series
EP1311G8 EP1313G8
EP1310G8
3.4 GPM 4.0 GPM
3.2 GPM
4,000
9.3 HP 10.7 HP
8.6 HP
.512 in./13 mm
