CC908-RF(ES) WIRELESS THERMOSTAT
CC908-RF(ES) can replace most common residential thermostat and is designed to be used
with electric, gas or oil heating control system or cooling system.
Unlike ordinary single unit design thermostat, this unit is a new type of thermostat
separating the thermostat function into two units. Receiver socket and Remote control transmitter
CC908-TR. The Control Centre serves as user interface and temperature sensing/control. User can
put the control Centre nearby and can read/control the temperature of really the living area while
put the Receiver besides the heating or cooling system. The unit is linked by RF.
Power source ............................ Control Centre 2 AA batteries
Frequency band............................ 433 MHZ
Relay contact .............................. 230VAC 10A
Room temperature setting range.........5℃ to 35℃ (41℉ to 95℉)
Accuracy.................................... ±1℉ or ±0.5℃
Dimensions................................. Control Centre 115mm×90mm×28mm
Color......................................... White
Can be placed anywhere in the home to detect and control the temperature of an area of the
user's choice. Not limited by power control wiring locations.
Link with the Receiver via RF. Control distance 100M open site.
Large LCD display
The screen displays the set temperature and the room temperature also time simultaneously
Permanent user setting and program setting retention during power loss
Optional temperature display of Celsius or Fahrenheit scale
Both Vacation mode and hold duration mode available for comfort and energy saving
Optional programming Period: 7 individual day or Separate 5-day (weekday) and 1-day/1-day
(Saturday/Sunday) programming with 4 or 6 separate time/temperature periods per day.
Display temperature recalibrates
Low battery indication
Anti-freezing protection
Pump protection available
Installation and operation instructions
SPECIFICATION:
Receiver 230VAC±10% 50/60HZ
Receiver 126mm×68mm×47mm
FEATURE:
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Celect CC908-RF
Summary of Contents for Celect CC908-RF
- Page 1 CC908-RF(ES) WIRELESS THERMOSTAT Installation and operation instructions CC908-RF(ES) can replace most common residential thermostat and is designed to be used with electric, gas or oil heating control system or cooling system. Unlike ordinary single unit design thermostat, this unit is a new type of thermostat separating the thermostat function into two units.
- Page 2 IMPORTANT SAFETY INFORMATION Always turn off power at the main power source by unscrewing fuse or switching circuit breaker to the off position before installing, removing, cleaning, or servicing this thermostat. Read all of the information in this manual before installing this thermostat. ...
- Page 3 ① Power on/ anti-freezing /off button ② Time setting button ③ Program setting button ④ Program run confirmation button ⑤ Reset button ⑥ Raise Temperature setting button ⑦ Lower Temperature setting button ⑧ Shows current day or days being programmed. ⑨...
- Page 4 SIGNAL RECEIVE/LEARN(YELLOW) SWITCH AND LED DESCRIPTION OF RECEIVER Special feature REMOTE CONTROL POWER RXD/LEARN ON Intelligent Recovery: See configuration menu item 6- POWER(RED) SIGNAL ON SIGNAL RECEIVE/LEARN(YELLOW) Intelligent Recovery operation. LEARN BUTTON ON/OFF BUTTON SELF CHECK FUNCTION : IF THE RECEIVER DID NOT ON/OFF LEARN RECEIVE THE SIGNAL FROM THE TRANSMITTER FOR...
- Page 5 ③ 09 （P6） P4/P6 Programming period per day option ③ 0：no backlight，5：backlight maintain 5 sec，10： 10（5） 0/5/10 backlight maintain 10 sec Press button ④ revert to the program operation Select temperature recalibrates Adjustment 3 LO to 3 HI – You can adjust the room temperature display up to 3 higher or lower. Your thermostat was accurately calibrated at the factory but you have the option to change the display temperature to match your previous thermostat.
- Page 6 program. See Planning your program section. shows when thermostat is in hold temperature operation. The thermostat will hold the room temperature at the selected setting. 3) Temperature override ▲ or ▼ until the temperature you want is During program operation, Press displayed.
- Page 7 Enter Heating Program 1). Press ③ once. 1 (indicating Monday program) will appear in the display. Also be displayed are the currently programmed start times for the 1st heating period and the currently programmed temperature (flashing), icon indicates 1 program period (Get up) setting。If the display shows 1 2 3 4 5, indicating that the 5-day program will be modified, you have a 5+1+1 day model.
