BATTERY TEST
B2. Press the
The following screen displays :
- 0.00 V
<->
This measurement is performed only with the single battery :
Place the positive pole (+) of the battery on the metal plate, so the negative pole (-) will be positioned upwards. Use the black precision probe (-) and place
it on the negative pole (-) of the battery.
SIMUL
Press the key to simulate the power consumption of the watch with a 1000 Ohm resistance. Read the battery voltage (under load) on the screen of
SIMUL
the device (2). Press again the
Caution : we recommend to limit the duration of the battery test to avoid that the battery discharges too quickly.
Do not touch the watch batteries with your hands to avoid a redox reaction on the surface of the battery.
C. Measuring the movement supply voltage
Connaître le point d'arrêt d'un mouvement est une information très importante permettant de définir l'origine de la panne.
Si la tension d'arrêt indiquée à l'écran est supérieure à celle donnée par le fabricant (exemple : mouvement ISASWISS 1198, tension d'arrêt 0.8 V), cela signifie
que le mouvement est encrassé ou endommagé. Ceci explique le besoin d'énergie supplémentaire.
Dépannage : nettoyer ou changer le rouage.
BATTERY
C1. Press the key on the main menu
The following screen displays :
SUPPLY 1.5V
C2a. Press the
The following screen displays :
1.50 V
TENSION
key of the submenu
Display of the sub-submenu
(1)
place the battery on the metal plate of the
key to remove the load of 1000 Ohm (1).
FLASHTEST
Display of the sub-submenu
TENSION
key of the submenu
Display of the sub-submenu
BATTERY TEST
device.
to measure the movement supply voltage.
TENSION
if the watch is supplied with 1.5 V.
SUPPLY 1.5V
9
- 0.00 V
<->
(2)
