ooma Door & Window Sensor Quick Start Manual

door & window sensor
Quick Start Guide
700-0163-200
Using the included adhesive pads or screws, mount
one piece of the sensor onto the moving part of your
door or window, and then mount the other onto your
door or window frame. These pieces should be
mounted so that when the door or window is closed
the dots are no more than 3/4 inch apart.
3/4" maximum
5
Key Features
Status indicator light
A
Magnet tab
B B
A
D
Quick release button
D
D
Pairing button
E
Tamper sensor
E
F F
E
Mounting plate
G
G F
G
1
Top view
Keep the front side of both pieces
even with each other if possible.
If needed, attach additional
risers (included) to raise the
height of the magnet tab.
6
Install the App Install the App
Step 1 Step 1
To get started, download and install the Ooma Home
Security app on your iOS or Android device.
The app can be found at: ooma.com/app
When the app is installed, log in using your Ooma
phone number and My Ooma password. If you forgot
your password, reset it at: my.ooma.com
Complete the initial setup in the app.
2
To get the best perfromance from your sensor, mount the
two pieces of the sensor such that they separate either
vertically or horizontally when the door or window opens.
If they separate laterally, the sensor may not
function properly.
7
Pair Your Sensor Pair Your Sensor
Step 2 Step 2
For the best pairing performance, hold your sensor within
10 feet of your Telo.
In the mobile app, press the "Add Sensor" button on the
Dashboard. Select the type of sensor you would like to pair.
Follow the instructions on your screen to pair your sensor.
10 feet
3

Additional Information

Starting pairing mode

Your sensor automatically enters pairing mode when
you insert the batteries. You can also press and hold
the pairing button for five seconds to start pairing mode.
Status indicator light blinks quickly when in this mode.

Checking battery level

Tap the pairing button to check the battery level.
A long flash indicates that the battery is good.
A slow blink indicates that the battery is low.

Status indicator reference

A
Pairing mode
Quick red flashes
Battery good
Long red flash
Battery low
Short red flashes
Software update
A Slow red double flashes
8
Mount Your Sensor
Step 3
If you are using the included adhesive pads to mount
your sensor, use a damp cloth to wipe the surface
where you are placing your sensor.
4
Need Help?

Support articles

www.ooma.com/support

User manuals

www.ooma.com/userguide

Community forum

forums.ooma.com
Live customer care
1-888-711-6662 (US)
1-866-929-5552 (Canada)

Legal

For warranty, safety, and other legal information,
visit ooma.com/legal
This device complies with part 15 of the FCC rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference,
and (2) This device must accept any interference
received, including interference that may cause
undesired operation.
9
