ooma motion sensor Quick Start Manual

Quick Start Guide
700-0168-200
Use the included adhesive pads or screws to mount
the sensor within range of the desired area.
Field of view = 85˚
Maximum range = 35 ft
5

Key Features

Status indicator light
A
(hidden)
Motion sensor lens
B
A
Standing attachment
C
B
C C
D
Pairing button
D
E F
Tamper sensor
E
G
Battery door
F
Magnetic mounting plate
G
1
If desired, the motion sensor may be mounted
in a 90˚ corner using these four screw mounts.
6
Step 1 Install the App
To get started, download and install the Ooma Home
Security app on your iOS or Android device.
The app can be found at: ooma.com/app
When the app is installed, log in using your Ooma
phone number and My Ooma password. If you forgot
your password, reset it at: my.ooma.com
Complete the initial setup in the app.
2
The included Standing attachment can be
used to install the motion sensor on any flat
surface without adhesive pads or screws.
7
Step 2 Step 2 Pair Your Sensor Pair Your Sensor
For the best pairing performance, hold your sensor within
10 feet of your Telo.
In the mobile app, press the "Add Sensor" button on the
Dashboard. Select the type of sensor you would like to pair.
Follow the instructions on your screen to pair your sensor.
10 feet
3

Additional Information

First time setup
After installing batteries for the first time, initial setup
lasts 30 secs. Status indicator blinks red until complete.
Starting pairing mode
Press and hold for pairing button for five seconds to
start pairing mode. Status indicator quickly blinks green
while in this mode.
Status indicator reference
First time setup
Quick red flashes
Pairing mode
Quick green flashes
Pairing success
Long green flash
Unpairing success
Slow red flashes
Motion sensed
Quick red flash
Signal disconnected
Long red flash
8
Step 3 Mount Your Sensor
If you are using the included adhesive pads to mount
your sensor, use a damp cloth to wipe the surface
where you are placing your sensor.
4
Need Help?
Support articles
www.ooma.com/support
User manuals
www.ooma.com/userguide
Community forum
forums.ooma.com
Live customer care
1-888-711-6662 (US)
1-866-929-6662 (Canada)
Legal
For warranty, safety, and other legal information,
visit ooma.com/legal
This device complies with part 15 of the FCC rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference,
and (2) This device must accept any interference
received, including interference that may cause
undesired operation.
