Summary of Contents for GROM Audio Vline
- Page 1 INSTALLATION MANUAL NISK www.gromaudio.com www.gromaudio.com/support.html...
-
Page 2: Table Of Contents
1.1 Before Installation 1.2 Tools 1.3 Vehicle Installation 1.4 Safety Guidelines & Appropriate Use Connect VLine Interface Cable to factory headunit ..........5 Display connections ....................6 Connecting to VLine....................6 Routing the GPS Antenna..................7 Routing the Microphone..................8 Mounting the VLine Module. -
Page 3: Package Contents
This is to ensure that no SRS airbags faults are triggered during the installation when disassembling the vehicles panels and wiring connections for the VLINE module installation. Please review the entire manual to familiarize yourself of the VLINE module and the installation requirements before installing the unit and using it. 1.2 Tools Have Tools ready for disassembling the dashboard panels to remove the stereo. -
Page 4: Safety Guidelines & Appropriate Use
• do not use VLine without running the engine for the extended period of time as it can drain the battery. Do not use Vline in a manner that would distract the driver or that may otherwise cause injury or death to vehicle occupants or bystanders. -
Page 5: Connect Vline Interface Cable To Factory Headunit
Step 1 - Install stereo touchscreen overlay Take out the stereo screen and disconnect it from the 24-pin factory connect- or. Mark this connector for yourself as you will need to replug it back to VLine video cable. Take the screen assembly to the comfortable place where you can install the touchscreen overlay. -
Page 6: Display Connections
(VNISK). Reconnect factory 24-pin connector back to VNISK female plug of the supplied interface cable. Carefully route all VLine cables (VNISK, MCFNISK, V-TOUCH) to the glove compartment, where you will connect them to VLine. Be extra carefull with V- TOUCH cable! Step 4 - Connecting to VLine... -
Page 7: Routing The Gps Antenna
(see below). Do not leave GPS antenna inside of the glove compartment, as it can affect the reception of GPS signal. Plug the VAUX cable into the port labeled CAMERA AV1 on the VLine. Plug the V-TOUCH cable, with TSB1 board attached, to the connector... -
Page 8: Routing The Microphone
We recommend to mount MIC nearby the rear view mirror but not directly on windshield glass. Avoid sticking to a hard surface as it will pick up more noise. Plug the microphone into the MIC port of the VLine module... -
Page 9: Mounting The Vline Module
Mount the module in a location free of any moving parts. We strongly re- commend mounting the module in an easily accessible location such as the glove compartment . It will provide easy access to the USB ports of VLine. Securely mount and install VLine module in a location free from heat, humidity, moving parts, or direct sunlight. -
Page 10: Understanding Vline Ports
Any USB device (Android, Keyboard / Mouse) MicroSD Insert microSD card (*pin side up) to increase storage space for Vline (up to 128GB supported). The microSD should be formatted FAT32. File system format exFAT and NTFS are not supported. Pin Side Up HDMI IN HDMI input connection to connect external video sources. -
Page 11: Chapter 2 - Getting Started
The location of XM tuner in your vehicle might be different, so please refer to your vehicle’s documentation or contact us for help. VLine will not work if you do not disconnect XM/SAT tuner in your vehicle! 2.2 Initializing... -
Page 12: Functions
Press the RADIO button until you are in XM/SAT mode of the stereo to enter into VLINE interface mode. For stereos with SAT button, press SAT button to activate VLine mode. NOTE: Please note factory XM/SAT function is disabled when installing VLine. -
Page 13: Support
TROUBLESHOOTING Stereo is not “seeing” VLine, or there is interference with XM/SAT - what can I do? Make sure to locate and disconnect XM/SAT tuner installed in your vehicle. I can’t get GPS signal - what can I do? Make sure GPS antenna is installed in the location that is free from obstacles or metal parts. -
Page 14: Grant Of License
GROM AUDIO VLINE Infotainment Upgrade System (hereinafter referred to as ‘GROM PRODUCT’) and its related software. THIS IS A LEGAL AGREEMENT BETWEEN YOU, AS “THE END USER”, AND GROM Audio (“GROM”). PLEASE CAREFULLY READ THE TERMS AND CONDITIONS OF THIS AGREEMENT BEFORE USING THE GROM PRODUCTS. -
Page 15: Operational Warning And Safety Instructions
IN CONNECTION WITH ANY BUSINESS, LOSS OF ANY GOODWILL, OR DAM- AGES. THE TERM ‘INCIDENTAL DAMAGES’ REFERS TO THE EXPENSES OF TRANSPORTING THE PRODUCTS TO THE GROM AUDIO SERVICE CENTER, LOSS OF THE END-USERS [ORIGINAL PURCHASER’S] TIME, LOSS OF THE USE OF THE PRODUCT, BUS FARES, CAR RENTALS OR OTHER COSTS RELATED TO THE CARE AND CUSTODY OF THE PRODUCT. - Page 16 RELATED TO SAID MOTOR VEHICLE OPERATION, AND THUS ANY DAMAGES CAUSED TO THE DRIVER OF THE VEHICLE, THE VEHICLE ITSELF OR ANY THIRD-PARTY AND ITS PROPERTY IS NOT THE RESPONSIBILITY OF GROM, ITS AGENTS OR ITS PRINCIPALS AND IS THE SOLE RESPONSIBILITY OF THE DRIVER OF SAID VEHICLE.
- Page 17 - in a manner that would distract the driver or that may otherwise cause injury or death to vehicle occupants or bystanders. GROM Audio is not in any way responsible for any such use by you. In all cases, GROM Audio may limit or revoke your use for any reason and at any time.
- Page 18 By using the Third Party Materials, you agree to comply with the use terms of the provider of such Third-Party Materials. GROM AUDIO does not warrant or endorse and does not assume and will not have any liability or responsibility to you or any other person for any Third Party Materials or for any other materials, products, or services of third parties.
- Page 19 EXEMPLARY OR CONSEQUENTIAL DAMAGES OF ANY KIND ARISING OUT OF OR IN ANY WAY RELATING TO THIS AGREEMENT, INCLUDING YOUR USE OF OR INABILITY TO USE THE VLINE OR ANY CLAIM MADE BY A THIRD PARTY (INCLUDING, WITHOUT LIMITATION, LOSS OF REVENUE, PROFITS, DATA OR...
- Page 20 Products, and your purchase hereunder, and supersede all statements or other agreements, whether oral or written, between you and GROM AUDIO. No change in this Agreement shall be effective, unless agreed to in writing by both, you, the end-user and GROM AUDIO.
