Summary of Contents for Sentera MTV-1/010-NA
- Page 1 MTV-1/010-NA 230 VAC POTENTIOMETER Mounting and operating instructions...
- Page 2 MTV-1/010-NA 230 VAC POTENTIOMETER Table of contents SAFETY AND PRECAUTIONS PRODUCT DESCRIPTION ARTICLE CODES INTENDED AREA OF USE TECHNICAL DATA STANDARDS WIRING AND CONNECTIONS MOUNTING INSTRUCTIONS IN STEPS TRANSPORT AND STOCK KEEPING INFORMATION WARRANTY INFORMATION AND RESTRICTIONS MAINTENANCE MIW-MTV-1-010-NA-EN-000 - 02 / 11 / 2016 2 - 7 www.sentera.eu...
- Page 3 MTV-1/010-NA 230 VAC POTENTIOMETER SAFETY AND PRECAUTIONS Read all information, the datasheet, mounting instructions and wiring scheme before working with the product. For personal and equipment safety, and for optimum product performance, make sure you entirely understand the contents before installing, using, or maintaining this product.
- Page 4 POTENTIOMETER PRODUCT DESCRIPTION The MTV-1/010-NA potentiometer is developed to control equipment requiring a 0—10 VDC control signal. The potentiometer needs a supply of 230 VAC and provides a stepless output signal of 0—10 VDC. It is suitable for both inset (IP44) and surface mounting (IP54).
- Page 5 MTV-1/010-NA 230 VAC POTENTIOMETER MOUNTING INSTRUCTIONS IN STEPS Before you start mounting your potentiometer, read carefully “Safety and Precautions” and proceed with the following mounting steps: For inset mounting Remove the knob by turning it to the right until it pops out.
- Page 6 MTV-1/010-NA 230 VAC POTENTIOMETER For surface mounting Remove the knob by turning it to the right until it pops out. Unscrew the loose nut to remove the cover of the external enclosure. Mount the external enclosure onto the surface by means of screws and dowels (not included) adhering to the mounting dimensions shown in Fig.
- Page 7 MTV-1/010-NA 230 VAC POTENTIOMETER MAINTENANCE In normal conditions this product is maintenance-free. If soiled, clean with a dry or dampish cloth. In case of heavy pollution, clean with a non-aggressive product. In these circumstances the unit should be disconnected from the supply. Pay attention that no fluids enter the unit.
