INSTRUCTION MANUAL
Collimated Beam Sensor $PSOL¿HU
LA-A1 / LA-A1P
CMJE-LAA1 (06)No.0042-36V
Thank you very much for purchasing Panasonic products. Read this Instruction Man-
ual carefully and thoroughly for the correct and optimum use of this product. Kindly
keep this manual in a convenient place for quick reference.
WARNING
Never use this product as a device for personnel protection.
In case of using devices for personnel protection, use products which
meet laws and standards, such as OSHA, ANSI or IEC etc., for personnel
protection applicable in each region or country.
1
FUNCTION DESCRIPTION
1
7
LA-A1
POWER
8
2
STB
SPAN
SHIFT
9
3
4
HIGH
ES
LOW
5
10
6
Description
Function
1 Power indicator (Green
Lights up when the power is supplied.
Light up in three steps in proportion to the
2 Stability indicators(Green×3)
intensity of received beam.
3 HIGH operation indicator(Orange)
Lights up when HIGH output is ON.
External synchronization
Lights up when the external synchronization
4
indicator (Green)
input is LOW.(Active-LOW)
External synchronization
Selects between gate trigger(
5
selection switch
trigger(
)
6 LOW operation indicator(Orange)
Lights up when LOW output is ON.
15-turn adjuster sets the span for the analog
7 Span adjuster
output voltage.
15-turn adjuster sets the offset for the analog
8 Shift adjuster
output voltage. It calibrates the output
voltage at zero input.
15-turn adjuster sets the HIGH output
9 HIGH level adjuster
threshold level.(Over-dark level).
15-turn adjuster sets the LOW output
10 LOW level adjuster
threshold level.(Under-dark level).
2
MOUNTING
Mounting on DIN rail
1.
Make sure the mounting stopper is
2
latched inside. Hook the front side
Stopper
1
of the controller on the 35mm width
35mm width
DIN rail at the bottom.
DIN rail
2.
Snap the controller down on the
Flathead screwdriver
35mm width DIN rail.
* 7R UHPRYH LQVHUW D ÀDWKHDG VFUHZ-
driver into the mounting stopper
and pull out.
Stopper
Mounting with screws
M4 pan head
screws
Use two M4 screws that are com-
Please arrange
mercially available. The tightening
separately.
torque should be 1.2N m or less.
3
CONNECTION
Wiring diagram
Receiver
Emitter
Cable
Connect color-coded wires in accordance
with the table below.The receiver wires
Color code
should be connected on the upper terminal
block and the emitter wires on the lower ter-
minal block.
9
8
7
6
5
4
3
2
Terminal
No.
2
Lower terminal block
3
5
4
3
2
1
for the emitter
4
9
8
7
6
Upper terminal block
5
for the receiver
LA-A1
Note: Do not connect any wire to the terminal No.1
POWER
STB
SPAN
SHIFT
I/O circuit diagram LA-A1 NPN
Terminal No.
Color code
Color code
s
(Brown) +V
9
Receiver
0V (Blue)
8
7
(Blue) 0V
Shield
6
75
5
(Gray) Analog output +
Emitter
0V (Blue)
(Shield) Analog output
4
SYNC.
(Pink) External synchronization input ES +
3
Shield
2
(Pink / Blue) External synchronization input ES
Sensor heads
Amplifier internal
Users' circuit
circuit
*1
Non-voltage contact or
NPN open-collector transistor
or
) / or edge
Low: 0 to 1V
High: +V or Open
I/O circuit diagram LA-A1P PNP
*1
Note
1): NPN When ES + (pink) and ES - (pink / blue) are connected, both HIGH and LOW
comparative outputs are triggered in the mode selected by the external synchronization
selection switch.
2):
PNP
When ES (pink/blue) and ES (pink) are connected, both HIGH and
LOWcomparative outputs are triggered in the mode selected by the external synchronization
selection switch.
3):To disable external synchronization, set the external synchronization selection switch on
'Gate trigger' and short-circuit the external synchronization inputs (ES + and ES -).
7R XVH WKH DQDORJ RXWSXW JUD\ FKRRVH D GHYLFH ZLWK DQ LQSXW LPSHGDQFH RI 0
more and connect the shield wire of the along output to 0V (common input) of the device.
5):Insulate all unused wires individually to avoid mis-contact.
Phone: 800.894.0412 - Fax: 888.723.4773 - Web: www.clrwtr.com - Email: info@clrwtr.com
4
EXTERNAL SYNCHRONIZATION FUNCTION
‡ The external synchronization input controls the timing or the effective
duration of the two comparative outputs. Either, edge, or, gate trigger is
selectable.
External synchronization
selection switch
ON
Terminal
Sensing signal
Color code
Color code
OFF
No.
6
Orange / Violet
7
High
External synchronization
8
input
Low
9
ON
Comparative outputs
HIGH,LOW
OFF
External synchronization input signal : LOW ... 0 to 1V, High ...+V or Open
Note: To disable external synchronization, set the external synchronization selection switch on 'Gate trigger' and short-
circuit the external synchronization inputs (ES+ and ES -).
5
ALIGNMENT
Beam alignment of sensor heads
‡ Make sure that, at least, one stability indicator lights up when you supply
Load
SRZHU WR DPSOLÀHU FRQQHFWHG ZLWK LA-305 sensor heads. While aligning sensor
Load +
heads, the more stability indicators light up, the more reliable detection can be
100mA max.
obtained.
‡ %HDP DOLJQPHQW VKRXOG EH SHUIRUPHG SULRU WR DQ\ DGMXVWPHQWV RQ WKH DPSOLÀHU
100mA max.
‡ If either sensor head moves out of position, do all adjustments, including beam
alignment, from the beginning.
Refer to the instruction manual of LA-305 for more details of beam alignment of sensor heads
Calibrating analog output
‡ The analog voltage output relates to the span and the shift adjustments as in
WKH ÀJXUH EHORZ
How to calibrate the output into 1 to 5V
*1
1. Block the whole beam to enter into the
darkest condition and set the output at
1V with the shift adjuster.
2. Allow the whole beam to be received to
enter into the lightest condition and set
the output at 5V with the span adjuster.
3. For more accurate calibration, repeat 1
and 2.
Explanation
(e.g.) Wire detection
Wire
A
B
C
Collimated beam
Further use of shift adjuster
‡ If you want to change the output voltage value after the calibration, the shift
adjuster enables you to shift the analog voltage up or down within about ±0.5V.
(e.g.) To shift the analog voltage from 2.51V to 3V with a certain amount of beam blockage
Collimated beam
Sensing object
(Application) When two sensor heads are used for width measurement the shift adjuster can
eliminate the need to move the sensor heads during set-up.
Reference width
Collimated
beam
Sensing object
Adjusting HIGH & LOW output levels (Two independent outputs)
HIGH output threshold level
Block as much of the beam for which you want
the HIGH output. Turn the HIGH adjuster to just
before the point where the HIGH operation indi-
cator lights up. The threshold level increases as
the adjuster is turned clockwise.
LOW output threshold level
Again, block as little of the beam for which you
RU
want the LOW output. Turn the LOW adjuster to
just before the point where the LOW operation
indicator lights up. The threshold level increases
as the adjuster is turned clockwise.
1RWH (LWKHU +,*+ RU /2: VHWWLQJ FDQ EH PDGH ¿UVW
6
MAJOR SPECIFICATIONS
Designation
Model No.
Applicable sensor head
Supply voltage
Gate trigger
Edge trigger
Current consumption
ON
Comparative outputs
(HIGH,LOW)
OFF
High
Low
ON
Aprox
40ms
OFF
Analog output
Ambient temperature
Ambient humidity
Material
Cable
Accessory
Note: Refer to the instruction manual of LA-305 for more details.
7
CAUTIONS
Make sure to use the exclusive sensor head LA-305 RQO\ DORQJ ZLWK WKLV DPSOL¿HU
‡ This product has been developed / produced for industrial use only.
‡ Make sure that the power supply is off while wiring.
5V
‡ Take care that wrong wiring will damage the sensor.
‡ Verify that the supply voltage variation is within the rating.
‡ If power is supplied from a commercial switching regulator, ensure that the
frame ground (F.G.) terminal of the power supply is connected to an actual
ground.
Span
‡ In case noise generating equipment (switching regulator, inverter motor,
adjustment
etc.) is used in the vicinity of this product, connect the frame ground (F.G.)
Shift
Incident
1V
terminal of the equipment to an actual ground.
adjustment
beam
intensity
‡ Do not run the wires together with high-voltage lines or power lines or put
Darkest
Lightest
them in the same raceway. This can cause malfunction due to induction.
condition
condition
‡ Extension up to total 50m, or less, is possible with 0.22mm
Use a shielded cable for extension of the analog output cable.
‡ In case of using this product as a CE marking conformity product, cable
extension of the power wire and I/O wire must be wthin 30m.
Incident beam width = A + C
‡ $PSOLÀHU WDNHV DSSUR[ PLQ WR VWDELOL]H LWVHOI DIWHU SRZHUXS 'R QRW XVH
Interrupted beam width = B
the output until stabilized.
Lightest condition: The entire beam is received.
‡ Make sure that stress by forcible bend or pulling is not applied directly to the
Darkest condition: The entire beam is blocked.
sensor cable joint.
‡ This sensor is suitable for indoor use only.
‡ Do not use this sensor in places having excessive vapor, dust, etc., or where it
may come in direct contact with water, or corrosive gas
‡ Take care that the sensor does not come in direct contact with water, oil,
grease, organic solvents, such as, thinner etc., strong acid or alkaline.
‡ Make sure to mount the terminal cover
Previous
Subsequent
8
INTENDED PRODUCTS FOR CE MARKING
Darkest condition
1V
1.49V
to
to
The models listed under "
Setting condition
2.51V
3V
CE Marking. As for all other models, please contact us.
to
to
Contact for CE
Lightest condition
5V
5.49V
Panasonic Marketing Europe GmbH Panasonic Testing Center
Winsbergring 15, 22525 Hamburg,Germany
Up to now, the sensor heads have had to be located
at the exact positions with respect to the reference
object to measure at the criterion of 3V, center of 1
to 5V. However, even a simulated center is easily
obtained by the shift adjustment, without any
Collimated
beam
realignment.
Note: To make the whole beam balanced between the lightest
and darkest conditions, the sensor heads should be posi-
tioned where the sensor generates 3V with the beam half
blocked.
High
LOW
output
level
HIGH
output
Incident
level
beam
intensity
Low
Darkest
Lightest
condition
condition
Comparative
ON
output (HIGH)
OFF
Comparative
ON
output (LOW)
OFF
$PSOL¿HUVHSDUDWHG FROOLPDWHG EHDP VHQVRU $PSOL¿HU
LA-A1
LA-A1P
LA305 Note
12 to 24V DC±10% Ripple P-P 10% or less
120mA or less (including sensor heads)
NPN open-collector transistor
PNP open-collector transistor
・Maximum sink current: 100mA
・Applied voltage: 30V DC or less
・Maximum sink current: 100mA
・Applied voltage: 30V DC or less
(between comparative output
and 0V)
・Residual voltage: 1.5V or less
・Residual voltage: 1.5V or less
(at 100mA source cur-
(at 100mA sink cur-
rent)
rent)
0.5V or less
0.5V or less
(at 16mA source cur-
(at 16mA sink cur-
rent)
rent)
Response time
0.5ms or less
HIGH OUT: ON when the received beam level is equal or lower than
Output
Over-dark level
operation
LOW OUT: ON when the received beam level is equal or higher than
Under-dark level
Short-circuit
Incorporated
protection
Analog voltage
・Output voltage: 1V (Darkest) to 5V (Lightest)
・2XWSXW LPSHGDQFH
Slew rate
8V/ms or more
Temperature
0.05%F.S./
or less
characteristics
0 to +50
(No dew condensation), Storage: -20 to +70
35 to 85% RH, Storage: 35 to 85% RH
Enclosure: Heat-resistant ABS, Terminal cover: Heat-resistant
ABS
Front cover: Polycarbonate
2
2
0.22mm
(Shield wire:0.15mm
) 7-core composite cabtyre, 2m long
Adjusting screwdriver: 1 pc.
2
, or more,cable.
MAJOR SPECIFICATIONS" come with
6
Advertisement
