Owners &
Freestanding Woodstoves
Installation Manual
www.regency-fire.com
MODELS:
F1103S
F3103L
Tested by:
Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4
919-045d
11.08.18
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Regency F1103S
Summary of Contents for Regency F1103S
- Page 1 Owners & Freestanding Woodstoves Installation Manual www.regency-fire.com MODELS: F1103S F3103L Tested by: Installer: Please complete the details on the back cover and leave this manual with the homeowner. Homeowner: Please keep these instructions for future reference. FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4 919-045d 11.08.18...
- Page 2 The following statements are required by the Environmental Protection Agency: “This manual describes the installation and operation of the Regency F1103 wood heater. This heater meets the 2015 U.S. Environmental Protection Agency’s crib wood emission limits for wood heaters. Under specific test conditions this heater has been shown to deliver heat at rates ranging from 10,600 BTU/hr. to 34,700 BTU/hr.”...
- Page 3 F1103S / F3103L...
-
Page 4: Table Of Contents
Copy Of Safety Label For F1103S .........5 Copy Of Safety Label For F3103L .........6 Unit Dimensions ............7 Wood Stove Outside Air Dimensions ......8 Residential Installation...........9 Room Air Important............9 Modular Installation Options ..........9 Minimum Clearance To Combustible Materials ...10 Stove Assembly Prior To Installation ......12... -
Page 5: Copy Of Safety Label For F1103S
COPY OF SAFETY LABEL FOR F1103S NOTE: Regency units are constantly being This is a copy of the label that accompanies We have printed a copy of the contents here each Regency Small Freestanding Woodstove for your review. -
Page 6: Copy Of Safety Label For F3103L
COPY OF SAFETY LABEL FOR F3103L This is a copy of the label that accompanies We have printed a copy of the contents here NOTE: Regency units are constantly being for your review. each Regency Large Freestanding Woodstove improved. Check the label on the unit and if (F3103L). -
Page 7: Unit Dimensions
UNIT DIMENSIONS F1103S Dimensions F3103L Dimensions F1103S / F3103L... -
Page 8: Wood Stove Outside Air Dimensions
WOOD STOVE OUTSIDE AIR DIMENSIONS With pedestal from base of unit to centerline 4-1/2" (114mm) Rear Front With bottom heat shield from rear heat shield to centerline F1103S - 5" (127mm) F3103L - 7-7/8"(198mm) Rear | F1103S / F3103L... -
Page 9: Residential Installation
MODULAR INSTALLATION OPTIONS The following items are required when assembling your Regency Stove. F1103 and F3103 units - the Rear Heat Deflector is supplied with the stove, but if you choose not to use it you must use the Airmate instead. -
Page 10: Minimum Clearance To Combustible Materials
Airmate 11" 6" 6" 23" 12.5" 18" with Rear Deflector 13" 5" 9" 25" 11.5" 21" Large F3103L with Airmate 18" 9.5" 10" 32" 16" 23.5" with Rear Deflector 20" 12" 10" 34" 18.5" 23.5" | F1103S / F3103L... - Page 11 Minimum Alcove Clearance to Combustible Materials The Regency Freestanding models have been alcove approved and must be installed with a listed double wall connector to the ceiling level. Note: Minimum alcove ceiling height - 84" Maximum depth of alcove - 36"...
-
Page 12: Stove Assembly Prior To Installation
The back of the airmate should be level with the back and sides of the rear heat shield. See Diagrams 2 & 3. Diagram 1 4) Push the Regency logo Diagram 4 into the two holes in the front bottom... -
Page 13: Step By Step Chimney And Connector Installation
4" duct pipe the 6" (152mm) flue dia. is 28.28 sq.in. with a mesh grill at the outside termination. At- tach the pipe to the 2 tabs with screws. Horizontal Installation F1103S / F3103L... -
Page 14: Masonry Chimney
Maintain proper clearance to the structure as recommended by the manufacturer. The chimney must be the required height above the roof or other obstructions for safety and proper draft operation. The space heater is to be connected to a factory-built chimney conforming to CAN/ULC-S629, Standard for 650 C Factory-Built Chimneys. | F1103S / F3103L... -
Page 15: Combustible Wall Chimney Connector Pass-Throughs
24 gage minimum sheet metal supports. See that the supports are fastened securely to wall surfaces on all sides. Make sure fasteners used to secure chimney flue liner. F1103S / F3103L... -
Page 16: Recommended Heights For Woodstove Flue
Recommended Flue Height Elevation Example a) Example b) 1000' 18.72' 21.84' 2000' 19.44' 22.68' WARNING: Operate only with door fully 5000' 21.60' 25.20' closed - open feed door to feed fire only. 8000' 23.76' 27.72' | F1103S / F3103L... -
Page 17: Listed Components For Mobile Home Installation
LISTED COMPONENTS FOR MOBILE HOME INSTALLATION The Regency Small and Large Freestanding pedestal units are approved for installation in a Mobile Home if one of the following pipe systems is used. U.S. Installation* Canadian Installations* AMERI-TEC HS Qty.Part #... -
Page 18: Stainless Steel Smoke Deflector Adjustment / Replacement
To replace the deflector, loosen off both bolts and slide defector upward and out. Install new defector and hand tighten bolts. Ensure positive location of the defector prior to hand tightening. WARNING: Operation of the unit with out proper installation of smoke deflector will void warranty. | F1103S / F3103L... -
Page 19: Brick Flue Baffle & Secondary Air Tube Installation
BRICK FLUE BAFFLE & Small Stove F1103S SECONDARY AIR TUBE 1) If the two air tubes are installed continue on to Step 2), if not, follow the instructions below. INSTALLATION Install the air tube into the holes in the side channels. -
Page 20: Brick Installation
GLASS INSTALLATION Bottom Shield Ash Drawer Kit (850-101 ) Your Regency stove is supplied with 5 mm Neoceram ceramic glass that will withstand 1) Remove the bricks from the floor of the the highest heat that your unit will produce. In firebox. - Page 21 (grounding) plug for your protection against shock when servicing controls. Wiring errors can cause hazard and should be plugged directly into a properly improper and dangerous operation. grounded three-prong receptacle. Do not cut or remove the grounding prong from this plug. F1103S / F3103L...
-
Page 22: Operating Instructions
Regency Stove causing ready to start a fire. Before establishing your door is left open for too long. -
Page 23: Ash Disposal
"MAN" and the top switch to either "HIGH" or "LOW". This will bypass the sensing 7) Your Regency stove can be very hot. You device and allow full control of the fan. may be seriously burned if you touch the stove while it is operating, keep children, Switching from "AUTO"... -
Page 24: Creosote
GLASS MAINTENANCE MAINTENANCE OF MAINTENANCE GOLD-PLATED DOORS Your Regency stove is supplied with 5 mm It is very important to carefully maintain your Neoceram ceramic glass that will withstand fireplace stove, including burning seasoned The gold electroplated finish on the door requires the highest heat that your unit will produce. - Page 25 Use only high temperature anti seize lube. (ie. never seize) Check glass for cracks Replace if required. Clean blower motor Disconnect power supply. Remove and clean blower. *DO NOT LUBRICATE* Inspect and clean chimney Annual professional chimney cleaning recommended. F1103S / F3103L...
-
Page 26: F1103 & F3103 Stove Main Assembly
Hinge Cap - Gold (2/set) 948-079 Hinge Cap Nickel (each) INSTALL EITHER "AIR MATE" 948-101 Spring Handle - Large Gold OR "REAR AIR DEFLECTOR" 948-135 Spring Handle - Large Nickel MAIN ASSEMBLY BLOWER/FAN (OPTION) | F1103S / F3103L SCREEN DOOR (OPTION) -
Page 27: Pedestal, Bottom Shield & Leg Options
Ash Plug Tool Handle 140) 850-126 Legs - Cast Black 850-127 Legs - Cast Gold 850-128 Legs - Cast Brush Nickel 948-216 Regency Logo - Gold 948-223 Regency Logo - Nickel *Not available as a replacement part. F1103S / F3103L... -
Page 28: Firebrick
Brick Partial: 1-1/4" x 1-1/4" x 9" Brick Partial: 1-1/4" x 3-1/8" x 4-1/2" Brick Partial: 1-1/4" x 3-3/8" x 9" Brick Partial: 1-1/4" x 4-1/2" x 8" Brick Partial: 1-1/4" x 4-1/4" x 8" *Not available as a replacement part. | F1103S / F3103L... - Page 29 F1103S / F3103L...
-
Page 30: Warranty
At all times FPI reserves the right to inspect reported complaints on location in the field claimed to be defective prior to processing or authorizing of any claim. Failure to allow this upon request will void the warranty. | F1103S / F3103L Revision Date: September 2018... - Page 31 Freight damages for products or parts are not covered under the terms of the warranty. Products made or provided by other manufacturers and used in conjunction with the FPI appliance without prior authorization from FPI may void this warranty. F1103S / F3103L Revision Date: December 2016 Regency Wood Products Warranty...
- Page 32 Product Registration and Customer Support: Thank you for choosing a Regency Fireplace. Regency strives to be a world leader in the design, manufacture, and marketing of hearth products. To provide the best support for your product, we request that you complete a product registration form at http://www.regency-fire.com/Customer-Care/Warranty-Registration.aspx...
- Page 33 Product Registration and Customer Support: Thank you for choosing a Regency Fireplace. Regency strives to be a world leader in the design, manufacture, and marketing of hearth products. To provide the best support for your product, we request that you complete a product registration form found on our Web Site under Customer Care within ninety (90) days of purchase.
- Page 36 Dealer Name & Address: ______________________________________________ ___________________________________________________________________ Installer: ___________________________________________________________ Phone #: ___________________________________________________________ Date Installed: ______________________________________________________ Serial No.: __________________________________________________________ Printed in Canada Regency and Classic are trademarks of FPI Fireplace Products International Ltd. © Copyright 2018, FPI Fireplace Products International Ltd. All rights reserved.
