Sunex Tools 6616 Owner's Manual

Atv/motorcycle lift
Hide thumbs
1
2
3
4
5

Advertisement

Table of Contents

OWNER'S MANUAL
CONTENTS:
Page 1 Specifications
2 Warning Information
3 Setup and Operating Instructions
4 Maintenance, Troubleshooting and Warranty Information
5 Exploded View Drawing and Parts List
SPECIFICATIONS
Capacity ...........................................3/4 Ton (1500 Lbs.)
Low Height ...................................................................4"
Raised Height ............................................................19"
Length .....................................................................38.8"
Chassis Width .........................................................18.5"
Lift Rails (2 each) .............................3" wide x 17" Long
Shipping Weight ............................................... 94.6 lbs.
MODEL 6616
CAPACITY: 3/4 TON
ATV/MOTORCYCLE LIFT
