OWNER'S MANUAL
CONTENTS:
Page 1 Specifications
2 Warning Information
3 Setup, Operating and Maintenance
4 Trouble Shooting and Warranty Information
5 Exploded View Drawing and Parts List
6 Replacement Parts
7800A
SPECIFICATIONS
Capacity ...................................................................... 800 Lbs.
Low Height ..........................................................................8.5"
Raised Height ...................................................................24.5"
Length ..................................................................................30"
Overall Width .......................................................................17"
Saddle Tilt Fore and Aft ............................................ 55° by 8°
Saddle Tilt Side to Side ...................................................... 30°
Shipping Weight ............................................................ 84 lbs.
1
7800A
800 LB. LOW PROFILE
TRANSMISSION JACK
© Copyright 2017, Sunex Tools ®
rev. 02/09/17
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Sunex Tools 7800A
Summary of Contents for Sunex Tools 7800A
- Page 1 Low Height ................8.5" Raised Height ..............24.5" Length ..................30" Overall Width ...............17" Saddle Tilt Fore and Aft ..........55° by 8° Saddle Tilt Side to Side ............30° Shipping Weight ............84 lbs. © Copyright 2017, Sunex Tools ® 7800A rev. 02/09/17...
- Page 2 Failure to read this manual completely and thoroughly and failure to understand its OPERATING INSTRUCTIONS, SAFETY WARNINGS, MAINTENANCE INSTRUCTIONS and comply with them, and neglecting the METHODS TO AVOID HAZARDOUS SITUATIONS could cause accidents resulting in serious or fatal personal injury and/or property damage. 7800A rev. 02/09/17...
- Page 3 7800A 800 LB. LOW PROFILE TRANSMISSION JACK OWNER'S MANUAL SETUP PLEASE REFER TO THE EXPLODED VIEW DRAWING IN THIS MANUAL IN ORDER TO IDENTIFY PARTS. Secure the #22 fingers to the #21 saddle with the #24 bolts and #23 washers provided.
- Page 4 4. Handle tends to raise up while the unit is under rated load. Pump the handle rapidly several times to push oil past ball valves in power unit. 5. Unit still does not operate. Contact Sunex authorized hydraulic service center. 7800A rev. 02/09/17...
- Page 5 7800A 800 LB. LOW PROFILE TRANSMISSION JACK PARTS DRAWING AND PARTS LIST Ref No. Part No. Description Ref No. Part No. Description Body Frame Washer M10 Lift Arm M10×20 Hex Bolt M6×20 Hex Bolt Long Connecting Rod Short Connecting Rod...
- Page 6 7800A 800 LB. LOW PROFILE TRANSMISSION JACK PARTS DRAWING AND PARTS LIST RS7800AO3 - Hydraulic Unit Assembly Ref No. Part No. Description RS7800A06 Clip 15-17 RS7800A07 Pump Plunger with Seals RS7800A08 Handle Swivel Seat Only Ref. No.'s identified above are available separately.
