OWNER'S MANUAL
CONTENTS:
Page
1
Specifications
2
Warning Information
3
Setup and Operating Instructions
4
Preventive Maintenance, Inspection, Proper Storage Troubleshooting and Owner/User Responsibility
5
Warranty Information
6
Hydraulic Maintenance Guide and Regular Maintenance
7
Exploded View Drawing and Replacement Parts for 6602ASJ
8
Exploded View Drawing and Replacement Parts for 6603ASJ
6602ASJ
6602ASJ
Maximum Capacity ...................................... 2 TON
Minimum Height ............................................... 3.5"
Maximum Height ............................................ 19.3"
Chassis Length ............................................... 26.5"
Overall Width ..................................................... 13"
Handle Length ................................................... 50"
Saddle Diameter ............................................... 4.6"
Shipping Weight ...................................... 52.9 Lbs.
Complies with ASME PASE-2014 Safety Standard
6602ASJ/6603ASJ
6602ASJ / 6603ASJ
6603ASJ
SPECIFICATIONS
6603ASJ
Maximum Capacity ...................................... 3 TON
Minimum Height ............................................... 3.8"
Maximum Height ............................................ 19.3"
Chassis Length ............................................... 26.4"
Overall Width ..................................................... 13"
Handle Length ................................................ 47.6"
Saddle Diameter ............................................... 4.5"
Shipping Weight ...................................... 58.4 Lbs.
CAPACITY: 2 AND 3 TON
ALUMINUM SERVICE JACK
© Copyright 2017, Sunex Tools ®
Rev. 2/6/17
