QUICK START GUIDE
QUICK START GUIDE
gen4-uLCD-50
5.0" Slim Intelligent Display Module with embedded
DIABLO16 Processor and Resistive or Capacitive Touch Panel
D/DT/DCT
What's included?
gen4-uLCD-50 (D/DT/DCT)
gen4-Interface Board
30-way Flat Flex Cable (FFC)
Supporting Documents
Datasheet, CAD step model, applicable
downloads, documents and application
notes are available on the 4D Systems
website.
Page 1 of 6
Advertisement
Table of Contents
Related Manuals for 4D systems gen4-uLCD-50 D
Summary of Contents for 4D systems gen4-uLCD-50 D
- Page 1 DIABLO16 Processor and Resistive or Capacitive Touch Panel What’s included? gen4-uLCD-50 (D/DT/DCT) gen4-Interface Board 30-way Flat Flex Cable (FFC) Supporting Documents Datasheet, CAD step model, applicable downloads, documents and application notes are available on the 4D Systems website. Page 1 of 6...
- Page 2 Adaptor). Alternatively, you can use the supplied FFC and the gen4- PA (Programming Adaptor) or 4D-UPA (Universal Programming Adaptor) and a micro USB Cable The 4D Programming Cable, uUSB-PA5-II Programming Adaptor, gen4-PA and 4D UPA are available separately from 4D Systems. (www.4dsystems.com.au) PROGRAMMER OPTIONS Page 2 of 6...
- Page 3 QUICK START GUIDE Power Up and Connect to a Computer Using gen4-IB & 4D Programming Cable 1) Connect one end of the FFC to your module’s 30-way ZIF socket with the metal contacts on the FFC facing up on the latch. 2) Connect the other end of the FFC to the 30-way ZIF socket on the gen4-IB* with the metal contacts on the FFC facing up on the latch.
- Page 4 QUICK START GUIDE Power Up and Connect to a Computer Using gen4-PA 1) Connect one end of the FFC to your module’s 30-way ZIF socket with the metal contacts on the FFC facing up on the latch. 2) Connect the other end of the FFC to the 30-way ZIF socket on the gen4-PA* with the metal contacts on the FFC facing up on the latch.
- Page 5 QUICK START GUIDE Start Using Workshop4 IDE 1) Open Workshop4 IDE and create a new project. 2) Select the display module you’re using from the list. 3) Select your desired orientation for your project. 4) Click next. 5) Choose a WS4 Programming Environment. Only the compatible programming environment for the display module will be enabled.
- Page 6 QUICK START GUIDE Follow steps 6b.1 to 6b.4 to scan and detect your display module 6b.1) Click on the COMMS tab, select the COM port the display module is connected to from the dropdown list. 6b.2) Click on the RED Dot to start scanning for the display module. A YELLOW dot will show while scanning.
