Connecting Auxiliary devices to your Valve80
The Valve80 has 2 AUX Inputs to allow other devices to be connected at any one time.
1. Turn OFF the power of your Valve80.
2. Connect the RCA Audio lead to either the AUX1 or AUX2 socket at the rear of the Valve80.
3. Connect the other end either RCA or 3.5mm connector to your source.
4. Select the correct AUX input using the Input Selector control.
5. Turn ON the power of the Valve80
NOTE: The Valve80 will take approximately 30seconds to warm up the valves, during this time no sound
would be played through the speakers.
6. Set your source to Play, if you have connected your source via the headphone socket set the volume to
maximum.
7. The source is now connected to your Valve80.

Amplifier Specifications

Output Power (RMS): (40W per Channel)
Frequency Response:

Harmonic Distortion:

Signal to Noise Ratio:
Input Sensitivity: 1.0V +/-5%
Input Impedance:
Output Impedance: 8
Power Supply:
Dimensions (W x H x D) : 368mm x 152mm x 165mm
Vacuum Tube Types: 6N x 2, 6E2 x 1
Connectors: iPod 30pin Dock Connector
Composite Video Output: S Video Output
Audio Input x 2; Speaker Output

Speaker Specifications

Driver:
Tweeter :
Impedance:
Max RMS Power:
Dimensions (W x h x D) :
20Hz - 20k Hz +/-1.5dB
0.5%
86dB
>4K
AC100  120V/50  60Hz
AC220  240V/50  60Hz
4" per Channel
1" Dome per Channel
8
50W per Channel
152mm x 254mm x 203mm
