Summary of Contents for MSI Optix MAG24C
- Page 3 I.Safety Prevention Measures Please always place The altitude and the Do not hold the plug Do not use a broken this device on a stable tropical environment w i t h w e t h a n d ; power plug nor keep surface;...
- Page 4 II.Installation Instructions 1.Accessories Power adapter Base/Stand Signal cable Warranty card User manual (The above pictures are for illustration only and the physical accessories shall govern.) 2. Adjustment of Rotation Angle 1. The screen may be inclined 5° The angle may be adjusted left forward and 20°backward.
- Page 5 III. Connect the Monitor to PC Before connecting the LCD monitor to PC, please power the PC and the monitor DP Port Connect the DP cable into the DP IN port of the monitor (this needs the support of the monitor).
- Page 6 IV. User Setup 1. Schematic Diagram of Keys 2. Description of Keys' Functions MENU key: Press this key to pop up the main menu/back to the previous menu (in case of main menu, exit). When a menu is open, press this key as the RIGHT key to enter the submenu;...
- Page 7 V. Operation Menu (OSD) Function Descriptions First level Second level Third level Instructions menu item menu item menu item Standard Normal use mode Movie Application mode of seeing film Mode First person shooting game mode Strategic game mode Eye Saver Eye-protecting blue light filtered application mode Inactivate dynamic contrast Activate dynamic contrast...
- Page 8 VI. FAQ Faults occurring Possible solutions The power indicator ◆ Check if the power is on. light is not on Check if the power cord is connected. ◆ Impossible plug-and-play ◆ Check if the function of plug-and-play of the device is compatible with PC.
- Page 9 VII. Product Specifications Picture Picture Diagonal Dot distance (mm) Optimal dimensions (mm) aspect ratio dimensions resolution 60cm(23.6″) 16:9 521.4*293.28 0.272*0.272 1920*1080 Storage -20 ℃ to 60 ℃ Ambient temperature temperature Working 5 ℃ to 40 ℃ temperature Humidity RH for operation R e m a r k : W h e n t h e r e s o l u t i o n a r e 2 5 6 0 * 1 4 4 0 @ 6 0 H z / 3 4 4 0 * 1 4 4 0 @ 6 0 H z / 1920*1080@144Hz/2560*1440@144Hz/3840*2160@30Hz connection via DVI port, pls choose 24+1 pin double - channel DVI cables.
