These are the main components of your machine.

Front view

1
control panel
2
scanner lid
3
top cover
4
output tray
5
output support
6
tray
Note
• All illustrations on this user's guide may differ from your machine.
• The surface of the output tray may become hot if you print a large number of pages at once. Please make sure that you do not touch the surface,
and do not allow children near it.

Machine overview

7
tray open button
8
scanner glass
9
top cover lever
10
toner cartridge
11
inner cover
1.2
