- Page 1 Rotary Drive M81135: Type 1 Rotary Drive 12 V M81136: Type 2 Rotary Drive 12 V M81137: Type 2 Rotary Drive 24 V Installation instructions English Date: 11-2006 Document number: 81174-5-EN © 2006 Raymarine UK Limited...
-
Page 3: Safety Notices
EMC conformance All Raymarine equipment and accessories are designed to the best industry standards for use in the recreational marine environment. The design and manufacture of Raymarine equipment and accessories conform to the appropriate Electromagnetic Compatibility (EMC) standards, but correct installation is required to ensure that performance is not compromised. -
Page 4: Waste Electrical And Electronic Equipment Directive
Warranty To register your new Raymarine product, please take a few minutes to fill out the warranty card. It is important that you complete the owner information and return the card to receive full warranty benefits. Alternatively you can register your product on line at:... - Page 5 Introduction Product description Welcome to the installation guide for the Raymarine rotary drive. This product is intended to operate the boat’s steering mechanism as part of a Raymarine autopilot system. It is designed for steering systems that can be driven from the helm position through a chain and sprocket (for example: cable and rod steering systems).
-
Page 6: Drive Specifications
Figure 2: Drive dimensions Drive specifications Table 1-1: Drive specifications Performance Type 1 (T1) Type 2 (T2) (at nominal voltage) M81135 (12 V) M81136 (12 V) M81137 (24 V) Maximum boat displacement 10,000 kg 20,000 kg (22,000 lb) (44,000 lb) - Page 7 Table 1-1: Drive specifications (Continued) Other information (applies to Types 1 and 2) protected for use in engine compartments CE approvals - conforms to: 89/336/EC (EMC), EN60945:1997 94/25/EC (RCD), EN28846:1993 Installation instructions Parts required To install this drive you will need: •...
-
Page 8: Installation Steps
18 Complete the post-installation check. 1. EMC installation guidelines All Raymarine equipment and accessories are designed to the best industry standards for use in the recreational marine environment. Their design and manufacture conforms to the appropriate Electromagnetic Compatibility (EMC) standards, but correct installation is required to ensure that performance is not compromised. -
Page 9: Suppression Ferrites
Typical suppression ferrites Connections to other equipment If your Raymarine equipment is to be connected to other equipment using a cable not supplied by Raymarine, a suppression ferrite MUST always be attached to the cable near to the Raymarine unit. -
Page 10: Mounting The Drive
2. Mounting the drive Mounting the drive involves four main steps: • securing the drive to the boat • connecting the drive to the steering system • ensuring correct sprocket alignment and chain tension • completing a steering check Securing the drive Mounting location Before you secure the drive to your boat, you must first check the suitability of the mounting location. - Page 11 • Environment: • This drive is not waterproof, so you should mount it in a dry location, clear of any bilge water. Mounting bolts Attach the mounting foot with two stainless steel M12 ( inch) bolts and lock nuts/lock washers. Before finally tightening the bolts you must check sprocket alignment (see page 14) and chain Note: tension (see page 15).
- Page 12 The sprocket sizes in Figure 3 provide good steering performance for most boats. If you think Note: your boat may have unusual steering characteristics, contact Raymarine’s Technical Services Call Center or an Authorized Service Representative for advice. Obtaining the steering sprocket Obtain the appropriate sized steering sprocket from the steering system manufacturer.
-
Page 13: Drive Sprocket
To stop the drive sprocket rotating on the drive shaft, the shaft has a inch square projection (a woodruff key) that fits into a notch (or keyway) at the centre of the sprocket. If you use a non-Raymarine drive sprocket, its bore and keyway dimensions must fall within the ranges specified in Figure 4 for it to lock correctly to the drive shaft. - Page 14 Steering sprocket Steering sprocket Drive sprocket Drive sprocket Side view End view D5085-1 Figure 5: Sprocket alignment Adjusting the chain tension Adjust the chain tension until it is just tight, so there is minimal lost motion between the drive sprocket and the rudder stock. If the chain tension is not set correctly, the resulting lost motion will impair steering performance.
- Page 15 D5086-1 Figure 6: Adjusting chain tension Steering check When you have tensioned the chain correctly, turn the steering wheel from hardover to hardover to check that the chain and sprockets move freely and are correctly aligned. WARNING Moving parts Keep clear of moving steering systems at all times. Protect moving parts from access during normal use.
- Page 16 • clutch: a two-core cable with red (+) and blue (-) cores Follow these steps to connect the rotary drive to the course computer: 1. Measure the total distance of cable run from the drive unit to the course computer: Table 1-1 •...
-
Page 17: Post Installation Checks
• check chain and sprockets are correctly aligned and tensioned • lightly grease sprockets and chain • check cables for signs of wear or damage If this drive is used heavily, we recommend that it is serviced every two years by a Raymarine Au- Note: thorized Service Representative. -
Page 18: Emc Servicing And Safety Guidelines
Electromagnetic Compatibility (EMC). • Always report EMC-related problems to your nearest Raymarine dealer. We use such information to improve our quality standards. - Page 20 www.raymarine.com...
