48"W McKenzie Alder Bookcase
Door Kit
AEGAC = Glazed Antique Cherry finish; AEGSP = Glazed Spice finish;
AECAF = Caffè finish
Congratulations!
This fine piece of furniture will make a gorgeous addition to
your home. For the best results, read the Assembly
Instructions before you begin your project.
Service Policy: We will replace any part that is defective,
missing or damaged during assembly. For a replacement
part, directly contact Whittier Wood Products customer
service department by phone, fax, mail or email.
Hours: Our friendly customer service staff can be reached
Monday-Friday 7:00 a.m. to 5:00 p.m. (Pacific Time). You
may leave a message 24 hours a day, seven days a week.
800-653-3336 • Outside the U.S. or Canada: 541-687-0213 • Fax: 541-687-2060
www.whittierwood.com • P.O. Box 2827 • Eugene, Oregon 97402, U.S.A.
P.O. Box 2827
Eugene, OR 97402 USA
CALL US FIRST! Do not return this item to the store
IMPORTANT NOTES:
• For normal household use only. Not recommended for commercial use.
• Do not climb, sit or stand on this piece of furniture.
• Before you begin your project, completely read the Assembly Instructions.
• Store this item: 1- in its box; 2- in a dry place; 3- in temperatures that
range from 40°F to 90°F (not on a cold and possibly damp cement floor.)
• Periodically inspect your furniture for any loose glue joints, screws or
any other problem that might affect the stability of your furniture.
Tighten or repair as needed.
Notice to California Customers
California Prop 65 requires consumer goods to be labeled if any one of
850+ different chemicals or substances, including wood dust, is present
even in trace amounts. Drilling, sawing, sanding or machining wood
products generates wood dust, a substance known to the State of
California to cause cancer. Warning: This product contains a chemical
or substance known to the State of California to cause cancer, birth
defects or other reproductive harm. California Health and Safety Code
Section 25249.6
DESIGN SUBJECT TO CHANGE WITHOUT NOTICE.
To Order: Provide the finish and furniture model number
(upper portion of this page), the part letter, production
code, quantity needed, reason for replacement and your
full name, address and telephone number.
Parts ship from our Eugene, Oregon factory within one or
two business days from the time we receive your request.
Please allow five to ten business days for delivery.
Production Code:
WARNING
06/14
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Whittier Wood 2002AEGACa
Summary of Contents for Whittier Wood 2002AEGACa
- Page 1 For a replacement (upper portion of this page), the part letter, production part, directly contact Whittier Wood Products customer code, quantity needed, reason for replacement and your service department by phone, fax, mail or email.
- Page 2 2002AEGACa; 2002AEGSPa; 2002AECAFa 48"W McKenzie Alder Bookcase Door Kit — Parts List Please identify the parts and check that quantities received match those on this list. If you need to replace a part, refer to the following letter and model number.
- Page 3 2002AEGACa; 2002AEGSPa; 2002AECAFa 48"W McKenzie Alder Bookcase Door Kit Assembly Instructions Tool Required: Phillips Screwdriver 1. Add washers to four of the eight Hinge Plates (E). You will attach the Vertical Divider Hinges (G) to these Hinge Plates (E)/Washers (H) assemblies. See Figures 1a, 1b and 1c.
- Page 4 Lay two Doors (A) face down on a clean, protected surface. There are predrilled holes in the doors as shown in Figure 3. This is where you will be inserting the hinge part of the assembly. Insert the Side Panel Hinge (D) assembly that has the plastic knobs into the predrilled holes in the bottoms and tops of the Doors (A).
- Page 5 Fixed Center Shelf Vertical Divider Side Panel Bottom Fig. 5 Fig. 5a Fig. 5b Center Shelf 5. Attach the door with the Side Panel Hinges (D) to the side panels of the bookcase (see Fig. 5b) by inserting the screws in the Hinge Plate (E) into the second and third holes up from the bottom of the bookcase unit.
- Page 6 7. Attach the Knobs (B) to the Doors (A) with #8x1-1/2 " Machine Screws Tuscan (Ca). See Figure 7. Ca x 4 B x 4 Fig. 7 Door 8. Attach a Pad (F) to the back of each door where it comes in contact with the adjustable shelf. F x 4 Page 6 —...
