• Blue:

• Brown:

If the wires in the mains lead do not match the colors marked in your plug, do the

following:

You must connect the green and yellow wire to the pin marked by the letter "E" or by the

safety 'Earth symbol' or colored green and yellow or green.

You must connect the blue wire to the pin which is marked with the letter "N" or colored

black.

You must connect the brown wire to the pin which is marked with the letter "L" or colored

red.

You must have a 13 amp fuse in the plug, adaptor, or at the distribution board.

Neutral

Live
