introduction
These are the main components of your machine:
This chapter includes:
•

Machine overview

• Control panel overview
• Understanding the Status LED
• Acknowledging the status of the toner cartridge
MACHINE OVERVIEW

Front view

Document width guides
1
ADF
2
Control panel
3
Output support
4
Front cover
5
Front cover handle
6
Tray 1
7
Document input tray
8
20 _Introduction
Document output tray
9
USB memory port
10
Toner cartridge
11
Imaging unit
12
Waste toner container
13
Scanner lid
14
Scanner glass
15
Scan unit
16
• Menu overview
• Supplied software
• Printer driver features

Rear view

Extension telephone socket
1
(EXT)
Telephone line socket
2
Network port
3
USB port
4
Handle
5
Power receptacle
6
Rear cover
7
Power switch
8
