Formax Cut-True 31H Operator's Manual

Hydraulic guillotine paper cutter
Hide thumbs Also See for Cut-True 31H:

Advertisement

Quick Links

Download this manual
Cut-True 31H
Hydraulic Guillotine Paper Cutter
MyBinding.com
5500 NE Moore Court
Hillsboro, OR 97124
Toll Free: 1-800-944-4573
9/2017
Local: 503-640-5920
OPERATOR MANUAL

Advertisement

loading
Need help?

Need help?

Do you have a question about the Cut-True 31H and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Formax Cut-True 31H

Summary of Contents for Formax Cut-True 31H

  • Page 1 Cut-True 31H Hydraulic Guillotine Paper Cutter MyBinding.com 5500 NE Moore Court Hillsboro, OR 97124 Toll Free: 1-800-944-4573 OPERATOR MANUAL 9/2017 Local: 503-640-5920...

  • Page 2: State Of Delivery

    1. TRANSPORTATION AND STORAGE 1.1.State of delivery The Cut-True 31H cutter is dispatched by the manufacturer in the complete assembled state and ready to operat. The machine is equipped with side-tables which will be delivered unmounted and have to be installed refer to drawing 1.
  • Page 3 1.2. Cutter levering Drawing 2. Adjustment of cutter positioning The cutter does not need to be fixed to the ground. A correct and stable positioning of the machine is done by adjusting the foot rotation, shown in Drawing 2 . It is responsibility of the user to create such working conditions for the cutter to be set properly to eliminate possibility of the operator injury.

  • Page 4: Main Parameters

    2. MACHINE TECHNICAL INFORMATION 2.1. Destination The cutter is designed for cutting: a pile of paper, cardboard and other materials, such as: plastics, etc. It is used in printing houses, bookbinders, work-shops and offices. 2.2.Main parameters 2.2.1. Technical data Table 1. Maximum paper width 28.7"...
  • Page 5 2.2.2 Machine dimensions Drawing 3. External dimensions MyBinding.com 5500 NE Moore Court Hillsboro, OR 97124 Toll Free: 1-800-944-4573 Local: 503-640-5920...

  • Page 6: Construction Of The Machine

    2.3. Construction of the machine e cutter consists of three main mechanisms: knife, clamp and backgauge drives and other additional devices. 2.3.1. Knife driving mechanism Drawing 4. Kinematic diagram of the knife driving mechanism The driving mechanism for the knife is shown on Drawing 4. Hydraulic double – acting cylinder (actuator) 1 is fixed on the knuckle 2.
  • Page 7 work tables plane. Inclination of the slide ways at different angles allows inclination of the knife bottom edge at the same angle, when the knife moves down. It decreases a force required for cutting, and the cutting accuracy is increased. The knife is so guided that in its bottom position the blade is parallel to the under knife cutting stick, and penetrates it up to 0,5 mm depth.
  • Page 8 – acting cylinder (actuator) 1 through the levers 2, pulls clamping beam 3 down. Clamping beam 3 is shifted in the slideways (not stated on the drawing) , that guarantees its parallelism to the cutting line. Lowering down the clamp bar 3 is possible also by pressing foot pedal 4. Pushing the pedal 4 moves the bar 5 into the lower position.

  • Page 9: Control System

    6 is connected with the feed screw 3, that allows measuring and displaying positions of pushing bar 4. 2.3.4 Control system Drawing 7. Operation and signalization. 1. Main on-off switch, connecting and disconnecting circuit from the power supply Push button, red color, (emergency switch), used for stopping the control system and prevents the cutter start up 3.
  • Page 10 5. Cutting buttons for two-hand activation of cut cycle 6. Knob for the clamp pressure adjustment: - in order to reduce the pressure turn the knob left - in order to increase the pressure turn the knob right 7. Diode. -red, system switched off -green, system switched on 8.

  • Page 11: Protection Against Hazards

    3. PROTECTION AGAINST HAZARDS 3.1. Hazards to be expected The potential hazards resulting with the cutter construction and operation, and safety means to eliminate such hazards are presented in table; layout of the safety items is shown schematically on drawing 9. The cutter is the type of the machine, where repetitious access to the dangerous clamping and cutting zone for the operator is needed.
  • Page 12 Chart 2. Factors and / or danger places Identification Item Drawing MECHANICAL 03.00.00 Levers for the clamping bar - permanent shield 1,3,8 01.00.00 drive mechanism 10.00.00 Motor, belt transmission for the - permanent shield 10.00.00 clamping bar drive mechanism - permanent shield 01.00.00 Motor, belt transmission for the pushing bar drive mechanism...
  • Page 13 Sharp edges and corners of the - breakdowns, dulls, cutter elements roundings - precise machining of piece 10. Uneven or rough surfaces - varnish coatings II ELECTRICAL Direct contact of the active - basic protection, electrical 12.00.00 elements gear in the closed recess - additional protection, 2.
  • Page 14 4. INSTALLATION OF PAPER CUTTER The users obligation is to prepare a good condition for the machine installation which will prevent any stumbling and slippage of the operator due to bad floor condition, incorrect wire location or poor access to the machine. The paper cutter is delivered with 5 wire, copper cable with diameter 2,5 mm2.
  • Page 15 5. USING THE PAPER CUTTER Drawing 10. Elements used when turning the cutter on Put the main switch 1 into the “on” position to power the machine. Press the green button 2 “I” starting the cutter system (green diode 3 lights). If there is no obstacle in the light barrier zone the green diode 4 lights, If there is any obstacle red diode 5 lights.
  • Page 16 5.1. Backgauge position set Setting the position of backgauge is done by program module 1 or the fine tuning manual crank 2 - drawing 11.The program positioning and operation of backgauge is described in the program module manual. For manual movement of the backgauge press crank 2 in and rotate it forwards or backwards.
  • Page 17 5.2 Clamping Bar The cut material is clamped automatically after pressing both cut cycle buttons 1(drawing 12) . To press the material without cut, press the foot pedal. The material is pressed until the pedal is released by operator. The clamp force is adjusted by knob 2 of force regulator 3 (drawing 12) Rotating the knob moves the indicator 3 in the box up when increased and down when decreased.
  • Page 18 Drawing 12a. Please mind the following rules: - The higher the pile the bigger force - The bigger the pile size the bigger force - The harder the paper pile the bigger force MyBinding.com 5500 NE Moore Court Hillsboro, OR 97124 Toll Free: 1-800-944-4573 Local: 503-640-5920...
  • Page 19 5.3 Cutting Elements of operating and signalization used during cutting shown on drawing 13. Drawing 13. Operation and signalization during cutting Before cutting, check to make sure there are no objects in the working area and if the in addition make sure the green button 2 is pressed. Push-buttons 3 simultaneously to engage the cutting cycle starts.

  • Page 20: Knife Change

    The Introduction of any object /ex. hand/ into the protected area by the no-contact protective device /light barrier/ 3 cause stopping of the clamp bar and knife down movement. To continue the cutting cycle, the object should be removed from this protected area and again switching-on both push-buttons 4.
  • Page 21 Drawing.15 6.1.1.4 Unscrew screws 1(drawing 15) mounting the cover 2 and remove the cover Drawing.16 6.1.1.5 Unscrew and remove the screw 1, the first one to right side of the knife bar. 6.1.1.6 Turn on electric system by rotating the main switch 2 (drawing 16) into...
  • Page 22 Single knife paper cutter manual type G73 H position „I”. 6.1.1.7 Turn on cutter system by pressing the green button 3. 6.1.1.8 Turn the Knife change mode off 4, following 6.1.1.1 directions. Press simultaneously buttons 5. Knife moves to its upper position (drawing 16). Drawing 17.
  • Page 23 Drawing 18. Drawing 19. 6.1.1.12 Holding the blade change tool 1, release from the bar by rotating the handles by ½ turn to left simultaneously, and carefully guide the knife downward and out (drawing 19). Place the removed knife into the special protective package (drawing 20), with a...

  • Page 24: Knife Installation

    cutting edge to the inside, fix with two bolts, and unscrew the tblade change tool 1. Drawing 20. Knife package 1 - Board 2 - Frame 3 - cover 4 - knife 5 - screws 6 – washer 7 - nut 6.1.2.
  • Page 25 WARNING: The new knife must be supported by its up edge on the knife bar. Not obeying this rule may cause machine overload and possible damage if the new knife is higher then the old one. Drawing 21.Adjusting screws position. 6.1.2.2.
  • Page 26 Drawing 22. 6.1.2.3. Holding the screws 1 put the knife 2 into the cutter, and match the blade change tool screws into the knife bar gaps 3. (drawing 23) Drawing 23. Put the knife to upper position until its up edge touches the bar lobe 2 (drawing 21).
  • Page 27 Drawing 24 6.1.2.4 Mount the knife by rotating right with force both screws 1 (drawing 24) 6.1.2.5 Input the mounting screws 2 (drawing 24) 6.1.2.6 Unscrew both screws 1 (drawing 24) and put into its position mounting screws 1,2 (drawing 25) Drawing 25.
  • Page 28 6.1.2.7 Unscrew gently first screw from left 2 (drawing 24) paying attention the head of screw does not stick out the knife bar slide. 6.1.2.8 Activate the "Knife Change" mode from the control panel.. 6.1.2.9 Press simultaneously cutting buttons 2 (drawing 26) to start cut. Knife stops in lower position.
  • Page 29 6.1.2.15. Turn the "Knife Change" mode off from the control panel. 6.1.2.16. Press simultaneously buttons 2. Knife moves into its upper position. 6.1.2.17. Turn off the Power supply by rotating button 5 into ”O” 6.1.2.18. Strongly fasten the first screw from the left side 2 (drawing 24) 6.1.2.19.
  • Page 30 6.2 Cutting stick change The cutting quality of the stack bottom sheets and rate of the knife efffectivness, depends largely the quality of the cutting stick. Changing or rotating the stick is recommended after each knife change, or when the bottom sheets are found to be ripped /not completely cut/. Drawing 28.
  • Page 31 Drawing 29. Cutting stick removal Stick usage Drawing 30.
  • Page 32 tick can be turned in both directions and can be used in four positions as shown on drawing 30. IMPORTANT: The chanel between the tables where the stick is assemblied has to be clean. 6.3 Parallelism of the backgauge Depending required deviation of the pushing bar 1, it is necessary to perform adjust shown on drawing 31.
  • Page 33 - lock the adjusting screws 3 with nuts 2; - tight with force screws 1. After a trial cutting, repeat adjusting, if it is necessary, the cutting parallelism is obtained. 6.4 False clamp alse clamp prevents against arising imprints from the down part of the clamp on the cut material Drawing 32.
  • Page 34 Drawing 33. False clamp location (before fixing on the clamping beam) In order to fix the false clamp on the clamping beam: • false clamp 1 on the cutting stick 2 - radius defining the line should cover the front false clamp surface (drawing 34) •...
  • Page 35 0 mm Maximum pile height during the cut with false clamp will be 96 mm (100 mm without the false clamp). When the false clamp is not fixed on the clamping beam it should be inserted under the front working table (as shown on drawing 33). control panel will work as the false clamp was fixed the clamping b .
  • Page 36 Drawing 35. Location of the screws, which block the false clamp MyBinding.com 5500 NE Moore Court Hillsboro, OR 97124 Toll Free: 1-800-944-4573 Local: 503-640-5920...
  • Page 37 7. MAINTANCE 7.1 Lubrication Lubrication can be done only if the machine is switched off. Location of lubrication points to be greased , every week is shown on drawings 32,33,34. Access to the stated lubrication points is possible after dissembling the shield shown on the drawing 32 1.
  • Page 38 7.1.1 Knife unit lubrication For the knife unit lubrication non-liquid grease to be used. ccess the knife unit elements is possible after removal of the cover 1 (drawing 36). Lubrication of the side guides and knife body contacted with the guides should be carried out in upper (drawing 37) and lower knife body position (drawing 38).
  • Page 39 Drawing 37 Locations of the knife lubrication locations (knife in Upper position) Drawing 38 . Locations of the knife lubrication locations (knife in lower position) 7.1.2 Backgauge lubrication In backgauge mechanism the following parts have to be lubricated: guiding roller (drawing 39) and located under the roller screw (not marked on the drawing).
  • Page 40 Drawing 39 Backauge lubrication points location 7.1.3 Clamp mechanism lubrication The parts of the clamping mechanism have to be lubricated with non-liquid grease. In the clamping mechanism the following parts should be lubricated: clamp bar runners 1 (drawing 36), roller bearing 2, running sleeves clamp mechanism 3, screw 4 (drawing 37) . In the cutter with hydraulic clamp beam drive positions 3 and 4 does not exist.
  • Page 41 Drawing 40 Clamp bar lubrication points location Drawing 41.Roller bearing 2, hydraulic actuators fixing 3, knife band head 4.

  • Page 42: Hydraulic System

    7.1.4 Hydraulic system verflow valve is set in factory to value 170 bar and sealed. The value can be controlled by manometer (included into unit) by connecting it to manometer slot. result a lose of warranty. 7.1.4.1 Working conditions - temperature in the room °...
  • Page 43 7.2. Inspections 7.2.1. General recommendation • Clean carefully after each work-shift /paper dust/. • Pay attention to cleanness of the control element contacts /contactors, switches/. • Check correctness of the cutter screw connections, and tight them, if necessary. • Check sealing of the hydraulic apparatuses connections. In case of seepage correct connection.
  • Page 44 Single knife paper cutter manual type G73 H 7.3. Regeneration of knife Quality and accuracy of the cutting depends totally on the knife sharpness and the correct choice of the cutting edge angle. 7.3.1. The features of the blunt knife: rough and uneven plane of stack to be cut;...
  • Page 45 Drawing 39.Deviations and roughness of the knife. 7.3.3. Selection of the grinding angle Depending on the cut down material, a ground off angles are between 16 and 26 Soft material needs a smaller grinding angle, whereas a hard material, a larger grinding angle.

  • Page 46: Electrical Equipment

    8.ELECTRIC DOCUMENTATION 8.1 Electrical equipment 8.1.1 Electric board Symbol Name Type Manufacturer ntity Contactor S-N12CX AC24V MITSUBISHI TMM 100VA BREVE – TUFVASSO Transformer 220/24V Melting fuse 3,15A S301 4A Over current release S301 6A Schneider / Legrand S301 4A Motor circuit breaker M250 In 6,3A Legrand Photocell power supply...
  • Page 47 8.1.2 Cutter Symbol Name Type Manufacturer ntity Cam switch 25A 4G25-10-US25 Apator L61QA21 Adapter Z33E Button START-STOP BACO 33E01 33E10 L21AA03 Button connector Adapter 33E01 BACO 33E10 – 2szt. LZ1KA03 Rotary switch Adapter 333E BACO 33E10 – 1pc Limit switch XCKP2102G11 Schneider S16N...
