  Summary of Contents for Samsung SPF-83H

  • Page 2: Installation

    Safety Symbols Safety Symbols Make sure to follow the directions below to prevent accidents and damage to the product. Failure to follow the accompanying directions may lead to serious injury or death. Failure to follow the accompanying directions may lead to minor personal injury or property damage. Safety Symbols Power The images here are for reference only, and are not applicable in all cases (or countries).
  • Page 3 Do not connect more than one appliance to a single outlet, as an overheated outlet may cause fire. Do not use force to pull the power cord. Don't place anything heavy on the power cord, as this may cause electric shock or fire. Make sure to turn the power off and disconnect the power plug from the outlet before moving the product.
  • Page 4: Safety Symbols

    Safety Symbols Installation When installing the product on a cabinet or shelf, do not let the front end of the product project beyond its front edge. Do not place the power cord near a heater, as the power cord may melt, causing electric shock or fire.
  • Page 5 Safety Symbols Using and Cleaning Do not insert any metal objects such as forks, wire, or gimlets, or flammable items such as paper or matches into the ports at the back of the product, as this may cause electric shock or fire. Never disassemble, repair, or modify the product yourself.
  • Page 6 disconnect the power plug. Correct Disposal of This Product (Waste Electrical & Electronic Equipment) - Europe only (Applicable in the European Union and other European countries with separate collection systems) This marking shown on the product or its literature, indicates that it should not be disposed with other household waste at the end of its working life.
  • Page 7 Features Features Expand the memory capacity with a memory card. Enjoy stored images immediately. By connecting a CF or SD/MMC/MS memory card of your digital camera to your Digital Photo Frame, you can enjoy the images on your Digital Photo Frame quickly and easily. This also provides a way to expand the memory capacity of your Digital Photo Frame.
  • Page 8 Quick Start Cables Power cord U.S.A. : 3903-000192 (Part No. are not applicable in all countries.) Features Front Features Back Warranty (Not available in all locations) USB cable (A-B type) (GK39-00013B) Components Front Components Front User Manual Power Adapter (BN44-00133A) Back Side Back...
  • Page 9 The Kensington lock is a device used to physically secure the system when using it in a public place. (The locking device has to be purchased separately.) Kensington lock For using a locking device, please contact where you purchased it. Connect the power adapter to this jack.
  • Page 10 Turns the product on or off. ] Power Button Power Indicator Connect the power cord to the power terminal of the power adapter. Shows the power status. When the product is powered on, the power light turns [MENU] Menu Button Displays the menu window at the bottom left corner of the screen.
  • Page 11 Allows you to insert an optional memory card. (Only applicable for CF/SD/MMC/MS card) Connect a PC or an external device using a USB cable. Down stream terminal Connect your Digital Photo Frame to a USB-supported. (Insert USB storage device)
  • Page 12: Memory Card

    Power Connect the power adapter to the Connect the power cord to the power adapter. Plug the power cord for the product into a nearby outlet. Press the button at the right of the product to turn the product on. Power terminal at the back of the product.
  • Page 13 Samsung carries no liability for external device malfunctions caused by using any cable except the standard cables specified for each device. Some external products provide a cable that does not meet USB standards. Hence, they may cause a malfunction.
  • Page 14 CF/SD/MMC/MS CARD Slide the card in the direction marked on the top of the card. When the power is turned on, the Photo menu screen appears automatically and a slide show starts with the photos in the Frame Memory. If external memory, such as a memory card or USB memory, is installed, it is selected first and a slide show starts with the photos in its root directory.
  • Page 15 When turning on the power, a slide show starts with the photo files in the root directory of the installed external memory device. If there are no photo files or no external memory device is installed, the Photo menu screen is displayed. If there are no key operations for five (5) minutes, the current mode changes to Clock mode to protect the screen.
  • Page 16 OSD : On Screen Display Open Open the folder. Copy Copy the folder. Delete Delete the folder. When Thumbnail list is selected When pressing the MENU, on-screen menu is displayed on the screen. When a file or folder name includes letters and numbers other than English, it may be displayed as '*'. This is neither an error of the product nor of the file.
  • Page 17 Select the Repeat for displaying images. Slide Show Shuffle Select whether to playback the files sequentially or in shuffle mode. 0~100 Brightness Adjust brightness from 0 to 100 levels. On, Off Auto Rotation If a photo is to be displayed in portrait mode while your Digital Album is placed horizontally, it is automatically displayed rotated and fit to the width.
  • Page 18 0~100 Brightness Adjust brightness from 0 to 100 levels. Update the product using an external memory(CF/SD/MMC/MS, USB). Firmware Update Please visit Model, Firmware Version System Information View the product information. Yes, No Reset Settings Reverts the product settings to factory defaults.
  • Page 19 Updating The update progression is displayed on the screen. When the update finishes, turn your Digital Photo Frame off, remove the USB memory card, and turn your Digital Photo Frame on again, for maximum safety. Do not remove the USB memory card during the update operation. Do not press any key during the update operation.
  • Page 20 The Digital Photo Frame not only allows you to appreciate photos but also provides an additional Mini-Monitor function. The Mini-Monitor is a function for using the Digital Photo Frame as an auxiliary monitor. Its usage is simple as the Digital Photo Frame connects to your PC via a USB cable. This function allows you to work more efficiently at your PC by using an additional monitor.
  • Page 22: Specifications

    Specifications Items Model Name Type Panel Resolution Interface Supported Formats Operating System Built-in Memory Memory Card Rating Power Consumption Content Files Photo File Dimensions (WxHxD) General Weight The product design may differ according to the model, and specifications are subject to change without prior notice for product performance enhancement.
  • Page 23 Specifications Supported Files Supported Files Resolution : Less than 8000x8000 Supported image file format : JPEG (not supported Progressive JPEG and YUV 422 V format)
  • Page 24: Troubleshooting

    Troubleshooting This section lists various problems and solutions encountered by users while using the digital photo frame. When encountering a problem, first check the list below and follow the suggested action if one matches your problem. If the problem still persists, contact or visit the nearest service center.
  • Page 25 Services Samsung Electronics web site If you have any questions or comments relating to Samsung products, please contact the SAMSUNG Check the file system on the memory card. Check the type of the USB memory device. This product may not support the compound USB device.
  • Page 26 TRINIDAD & TOBAGO 1-800-SAMSUNG(726-7864) VENEZUELA 0-800-100-5303 AUSTRIA 0800-SAMSUNG(726-7864) BELGIUM 02 201 2418 CZECH REPUBLIC 800-726-786 (800 - SAMSUNG) DENMARK 70 70 19 70 EIRE 0818 717 100 FINLAND 030-6227 515 3260 SAMSUNG (€ 0,15/Min) FRANCE 08 25 08 65 65 (€ 0,15/Min)
  • Page 27 400-810-5858 010-6475 1880 HONG KONG : 3698-4698 3030 8282 INDIA 1800 110011 1-800-3000-8282 INDONESIA 0800-112-8888 JAPAN 0120-327-527 MALAYSIA 1800-88-9999 NEW ZEALAND 0800 SAMSUNG (0800 726 786) PHILIPPINES 1800-10-SAMSUNG(726-7864) SINGAPORE 1800-SAMSUNG(726-7864) 1800-29-3232 THAILAND 02-689-3232
  • Page 28 TAIWAN 0800-329-999 VIETNAM 1 800 588 889 SOUTH AFRICA 0860-SAMSUNG(726-7864) TURKEY 444 77 11 U.A.E 800-SAMSUNG (726-7864) 8000-4726 Middle East & Africa
