Summary of Contents for Majestic REFLECTION 5.0
Page 1
REFLECTION 5.0 OCTAVE MARIMBA user manual...
Page 2
Components Item Parts Description Inner Carton Leg Assembly – Bass End (with height adjustment handle) 1/11 Leg Assembly – Treble End 2/11 Cross Bar – Bass End (straight) 3/11 Cross Bar – Treble End (curved) 3/11 Truss – Bass End 4/11 Truss –...
Wheels with brake should be positioned facing audience side. Make sure the pins in bracket are inserted into the holes on cross bar before tightening knobs. Bass end Treble end Serial number located on inner side. REFLECTION 5.0 OCTAVE MARIMBA user manual...
Page 4
Truss Assembly Assemble Truss 1. Assemble the truss ( F + G ) Loosen and remove the quick release mechanism on bass end truss. Connect the treble and bass truss sections together by fully inserting the connecting end of the treble section into the receiving end of the bass section.
Page 5
There will be a small gap between the two sections of the shaft once it has been assembled and connected properly to the treble end leg. To check whether the shaft is assembled properly, use the handle at bass end leg to adjust height. Both sides should move up or down simultaneously. REFLECTION 5.0 OCTAVE MARIMBA user manual...
Page 6
Resonator Assembly Slide resonator set onto the support arms extended from truss. There are 3 sections on each side. Due to package space constraints, the G#2 tuning cap is not pre- installed in the resonator tube. Be sure to insert this cap prior to setting up the resonators.
Rack Assembly Put the rack on top of the truss, bar posts facing up. Tighten the knobs (4 knobs every section) underneath truss to secure the racks. REFLECTION 5.0 OCTAVE MARIMBA user manual...
Page 8
Tone Bar Placement Natural Bars 1. Treble Section ( S ) Gently lay the treble section natural bars on rack. Bar cord should go around metal post before hooking on the inner side columns. Position each tone bar between bar posts, beginning from bass (large) end, working progressively toward treble (small) end.
Page 9
Gently lay the bass section acidental bars on rack. Bar cord should go around metal post before hooking on the columns at inner side. Repeat the same process as treble end. When tightening bar cord, be sure to pull the cord taut. REFLECTION 5.0 OCTAVE MARIMBA user manual...
Maintenance Notes 1. How to use tuning cap Syringe-inspired tuning system ensures an air-tight seal and allows for quick, easy adjustment to environment. Simply pull and push the rod of each tunable cap to ideal tonal position. All tuning caps were processed with lubricant to ensure smoothness.
Page 11
Maintenance Notes REFLECTION 5.0 OCTAVE MARIMBA user manual...
