Rugged Android Tablet
Quick Start Guide
For more information on this and
other Winmate products, please
visit our website at:
www.winmate.com
Document Part Number: 9152111K1057
Please read these instructions carefully before using this product, and save this manual for future use.
M101RK Series
V1.0
Advertisement
Table of Contents
Related Manuals for Winmate M101RK Series
Summary of Contents for Winmate M101RK Series
-
Page 1: Quick Start Guide
M101RK Series Quick Start Guide V1.0 For more information on this and other Winmate products, please visit our website at: www.winmate.com Document Part Number: 9152111K1057 Please read these instructions carefully before using this product, and save this manual for future use. -
Page 2: Getting Started
M101RK Rugged Android Tablet Quick Start Guide ❶ Getting Started Congratulations on purchasing Winmate® M101RK Rugged Android Tablet Computer. The rugged design allows you to use it in harsh outdoor environments. This quick start guide tells you step by step how to get the Tablet Computer up and running. -
Page 3: Description Of Parts
M101RK Rugged Android Tablet Quick Start Guide ❸ Description of Parts Front: Right: Item Description Item Description Front Micro HDMI Output 2 Megapixel Webcam Camera HDMI Micro Memory card reader Show the current SD Card port for Micro SD status of the Tablet Computer Red: Reader Card... - Page 4 M101RK Rugged Android Tablet Quick Start Guide Rear: Bottom: No Item Description Item Description RFID / NFC RFID reader for Latch to lock the (Optional) reading of RFID tags. battery in place Battery Kensington Provide lock access for once battery is Lock Latch inserted.
-
Page 5: Inserting Battery Pack
M101RK Rugged Android Tablet Quick Start Guide ❹ First-Time Operation Inserting Battery Pack Discontinue using device immediately if you notice the battery is swelling, or looks puffy or misshapen. Do not attempt to charge or use the device. Do not CAUTION handle a damaged or leaking battery. -
Page 6: Connecting To Power Supply
M101RK Rugged Android Tablet Quick Start Guide Connecting to Power Supply The Tablet Computer operates either on external AC power or internal battery power. It is recommended to use AC power when you start up the Tablet Computer for the first time. Use only the AC adapter included with your Tablet CAUTION Computer. -
Page 7: Turning Off
