DEMA 151 Installation Instructions

I. PARTS
A. Faucet Proportioner
B. ¼" ID x 8 ft. long vinyl supply tubing, foot valve and ceramic weight
C. Metering Tips (2 ea.)
II. INSTALLATION
This product is designed only to be used as described in this instruction sheet. Adhere to all warnings and
cautions identified in this document.
Screw proportioner directly onto garden hose type faucets. Remove inlet adapters for mounting onto standard
external aerator threads. For other faucets, see parts break-down for adapter part numbers. Select a metering tip (See
section 4), and screw it into the inlet barb (Figure 1).
Place the chemical container in a convenient location not more than 6 feet below the proportioner (greater lifts will
reduce injection capacities). Insert the vinyl supply tubing with the foot end into the chemical container. Cut the
vinyl tube to any convenient length that will allow it to extend from the bottom of the chemical container to the
proportioner inlet barb. (See Figure 1)
For filling buckets or mop rigs: a short length of open ended garden hose may be attached to the proportioner outlet.
Replace screen retainer part 100-8 with hose adapter part 100-10. Use one screen part 100-7 to insure priming.
I-101
Rev. C-41011 9/11/15
FAUCET PROPORTIONER
INSTALLATION INSTRUCTIONS
WARNING: Installations must conform to all local and national plumbing codes and use
approved backflow prevention and pressure relief devices where required.
ALWAYS DISCONNECT DISPENSER FROM WATER SOURCE WHEN DISPENSER
IS NOT IN USE.
Always read SDS for all chemicals used and follow personal protective guidelines.
DEMA 151
Pg. 1 of 5
