JBL GTO S649C Owner's Manual

Gto S649c Gto S649c
BL (Tm) 3.935 Vas (l) 8.5056
DcR (ohms) fs (hz)
2.15 69.1
Mms (g) 15.56 Qes 0.94
Sd (cm 2 ) 132.73 Qms 5.972
cms (µm/n) 0.341 Qts 0.812
SpecificationS Gto S649c
Type: 6-1/2" two-way car audio
component system
Peak power handling: 440W
Power handling, continuous average: 110W RMs
Recommended amplifier RMs power 5W – 200W
range:
Frequency response: 53hz – 21khz
nominal impedance: 3 ohms
sensitivity (2.83V/m): 93dB
GeneRaL caRe: Clean the speaker grilles with a damp cloth. Do not use any cleaners or solvents on the grilles or on
the speaker units.
WaRRantY: grand Touring series speakers are warranted against defects. The duration of the speaker's warranty
depends on the laws in the country in which it was purchased. Your local JBl ® car audio retailer can help you determine
the length of your warranty. To register your product, please go to www.jbl.com.
6-7/8"
(175mm)
5"
(127mm)
HARMAN International Industries, Incorporated
8500 Balboa Boulevard, Northridge, CA 91329 USA
© 2012 HARMAN International Industries, Incorporated. All rights reserved.
JBL and Grand Touring are trademarks of HARMAN International Industries, Incorporated,
registered in the United States and/or other countries.
Features, specifications and appearance are subject to change without notice.
Part No. JBLP4308 Rev. A
eSpecificaçõeS Gto S649c
Tipo: sistema de componentes de
som de carro de duas vias de
16,5 cm
Potência de áudio: 440 W
Potência de áudio, média contínua: 110 W RMs
intervalo recomendado de potência 5 W a 200 W
RMs do amplificador:
Resposta de frequência: 53 hz a 21 khz
impedância nominal: 3 ohms
sensibilidade (2,83 V/m): 93 dB
cUiDaDo GeRaL: limpe as grades do altofalante com um pano úmido. não use limpadores ou solventes nas grades
ou nas unidades do altofalante.
GaRantia: Altofalantes da série de grand Touring são garantidos contra defeitos. A duração da garantia do altofalante
depende das leis no país no qual ele foi comprado. seu revendedor local de áudio de carro JBl
determinar a duração da sua garantia. Para registrar o seu produto, acesse www.jbl.com.
Q Q
Q
e
D
Q
f
e
e
5/8"
(16mm)
13/16"
1-7/8"
(20mm)
(47mm)
1-5/8"
(41mm)
2-9/16"
2-1/4" 1"
2-1/16"
(65mm)
(56mm) (25mm)
(52mm)
2-3/16"
(55mm)
Grand TOurinG series
GTO S649C
Owner's Manual
pode ajudá-lo a
®
a
www.jbl.com
