Titan TOCS01 Manual page 3

FIGURE 8
Provisionally turn the LUX Control Knob to the edge
clockwise at the moon (dusk) position. (FIGURE 8) In
this provisional setting mode, the Motion Sensor
remains inactive during daylight. At dusk when you
find it is the LUX level you desired for operation,
simply set the LUX control knob to the position that
you tried satisfactorily.
OPERATION

Automatic Operation
When the sensor
automatically turns on. The built-in photocell turns
the sensor off and on according to the light level
selected by the LUX adjustment.
TROUBLESHOOTING
Light does not turn on

Confirm that you have made a correct "wiring
connection".

Make sure that the bulbs have not burned out..
Light remains on

Make sure the wiring connection is correct.

Check if the TIME setting is correct.
detects motion, the
SPECIFICATIONS
Power Requirement
Lighting Load
Detection Angle
Detection Distance
Mounting Height
Wall Switch Control
Time Adjustment
light
Lux Adjustment
Warm Up Time
Protection Class
Protection Degree
Safety
Specifications are subject to change without notice.
Warning:
Do not dispose of electrical appliances as unsorted
municipal waste, use separate collection facilities.
Contact
regarding the collection systems available.
If electrical appliances are disposed of in landfills or
dumps, hazardous substances can leak into the
groundwater and get into the food chain, damaging
your health and well-being.
3
AC 230V / 50Hz
Max. 8 A Incandescent or
Max. 6A Fluorescent
Up to 210w LED (dimmable
recommended)
360° MICRODETECTION
Up to 3.5m radius at 25°C at
2.5m Height
MICROMOVEMENT
Up to 5m radius at 25°C at
2.5m Height general
movement
Recommended 2.2 ~ 3m
Ceiling Mount
Auto/Off
Approx. 5 seconds to 40
minutes (5, 10, 20, 40, 80,
160 second & 5, 10, 20, 40
minute)
Approx. 30 ~ 200 Lux & test
mode
About 1 min
Class II
IP44
CE, GS
your local government for information
A501111210R
