PROGRAM
When HOLD contition is entered (lamp HOLD on) SET value is equal to SEt.H.
When HOLD lamp is off HP55 SET in the time is determinated by program condition:
SET
SEt.4
SEt.3
SEt.2
SEt.1
END 2
1
(see OPt.E)
SEt.E
i.1 i.2
SET
START
SEt.4
SEt.3
SEt.2
SEt.1
2
1
END
(see OPt.E)
SEt.E
i.1 i.2
START
i.1, i.2, i.3, i.4 are settable in hours and minutes from 0.00 to 96.00 (4 days). During HOLD status program
timer stay in progress. After black-out program timer return in progress from where was halted.
Number of segments is limitated to | OPt.P | .

INSTALLATION

How to connect the contacts
Connect terminals on the terminal
block (contacts up to 4AMP.AC1)
to the loads as shown in the
diagram.
How to connect the line
OPTION
Connect 230V line on terminals L-N
RX and TRIMMER under aluminnium cover
Protect supply with adequate fuse.
Recalibration:
HP55 is delivered calibrated for
thermocouple input (typ.
precision at full scale 0.2%).
HP55
Small adjust can be obtained by
Ad.tE COSt change.
For a N T C input accurate
recalibration apply 10 Kohm
resistor and trimmer to obtain on
display 25.0°C.
For a PT100 input accurate
recalibration apply 100 ohm
resistor and trimmer to obtain on
display 0.0°C.
As it company policy to continually improve the products the Manufacturers
reserve the right to make any modifications thereto without prior notice. They
cannot be held liable for any damage due to malfunction.
OPt.P = 4
3 4 END
(see OPt.E)
i.3 i.4
time (hh.mm)
OPt.P = - 4
3 4 END
(see OPt.E)
i.3 i.4
time (hh.mm)
SSR EXT. DATA T.C. *1) EXTERNAL COMMAND OPERATION:
- + OPER PROT. *3)
S.C. START cycle command (no if HP55 is
4V *1) *2) - +
in cycle).
100r END cycle command (END lamp flashes)
200r HALT timer but thermoregulate (segment
lamp flashes).
300r HALT timer and drift to T.amb (segment
lamp flashes and under key - is
displayed HALt).
400r put HP55 in HOLD condition (lamp
HOLD flashes; resume with START or
END command)
OPEN normal / resume from HALT condition
*2) DATA PROTECTION:
S.C. SETS are viewable but unchangeable
and COSt and boot is inhibited.
OPEN normal
*3) INPUT TYPE SELECTION
t E n P I n p u t t y p e
= 0 m V - 2 0 . 0 . . + . 5 3 0 .
t c ° C
= 1 J - 1 0 . . + . 7 5 0
= 2 K t c - 2 0 . . + . 1 3 0 0 ° C
= 3 N t c - 5 0 . . + . 1 3 0 0 ° C
t c ° C
= 4 R - 5 0 . . + . 1 7 0 0
S t c - 5 0 . . + . 1 7 0 0 ° C
= 5
= 6 T t c - 2 0 . . + . 3 8 0 ° C
= 7 N T C - 1 0 0 . . . + . 1 0
= 8 P T 1 0 0 - 1 0 0 0 . . . + . 4
P T 1 0 0 - 2 0 0 . . + . 4 8
= 9
= 8 P T 1 0 0 0 2 0 0 0 . . . + .
= 9 P T 1 0 0 0 - 2 0 0 . . + . 4
thermocouple programmable PID

MAIN SETTINGS (Run Mode).

START TIME-TEMPERATURE CYCLE.

Press START to switch-on time-temperature cycle: key lamp lights.
Pressing START during the cycle will be displayed time (hours and minutes)
passed from beginning phase: press + to go on next phase.
Phase in progress is indicated from its PROGRAM lamp.

SET TEMPERATURE HOLDING.

Press HOLD key to obtain thermoregulation temperature of value SEt.H
programmed under SET key: HOLD lamp lights (END disabled).
To return on thermoregulation program decided from cycle press again
HOLD key or START cycle: lamp off.

THERMOREGULATION PARAMETERS SETTING.

Press SET (key lamp flashes):
This message will be displayed instead of the
° Set arrival temperature of 1° segment.
Press + or - to modify, press SET to confirm.
At this point this message will be diplayed instead
of the ° Set arrival temperature of 2° segment.
Press + or - to modify, press SET to confirm.
At this point this message will be diplayed instead of the
° Set arrival temperature of 3° segment.
Press + or - to modify, press SET to confirm.
At this point this message will be diplayed instead of the
° Set arrival temperature of 4° segment.
Press + or - to modify, press SET to confirm.
R X
0 4 M 7
At this point this message will be diplayed instead of the
4 M 7
4 M 7
°Set end cycle .
4 M 7
Press + or - to modify, press SET to confirm.
4 M 7
4 M 7
4 M 7
At this point this message will be diplayed instead of the
0 0 . ° C 4 M 7
° C °C Set hold temperature.
8 0 0 . 2 4 K 9
0 ° C 2 4 K 9
Press + or - to modify, press SET to confirm.
4 8 0 0 . ° C 2 4 9 K
8 0 ° C 2 4 9 K
At this point this message will be diplayed instead of the
°C /minute rising rate limitation ( 0.0° : no-limitation).
Press + or - to modify, press SET to confirm.
HP55
SL 6.7
