Gallagher TWR-1 Weigh Scale Quick Start Guide
Thank you for purchasing the Gallagher TWR-1 Weigh Scale unit. The Gallagher
range of weighing systems is simple, tough, innovative and reliable.
BONUS OFFER
Register your product online at www.gallagherams.com to extend your
warranty to two years for free.
Follow these instructions for the setup and first use of the TWR-1.
Further information can be obtained by tapping
Contents
Box contents ............................................................... 1
Charging the battery ................................................... 2
Understanding the TWR-1 Weighing Unit ................... 3
Installation .................................................................. 4
Connecting equipment to the TWR-1 ......................... 6
Specifications .............................................................. 6
First time start-up ....................................................... 7
Start a session ............................................................. 8
View animal information........................................... 10
Care and maintenance .............................................. 11
Connecting the TWR-1 to a computer ....................... 11
Approvals and standards ........................................... 12
BOX CONTENTS
The Gallagher TWR-1 box contains:
•
Carry Bag
•
TWR-1 weighing unit
•
110V - 230V Mains AC adapter
•
USB cable
•
USB flash drive
•
12V battery cable with alligator clips
•
Mini Serial Adapter (2M1709)
•
Mounting bracket and mounting hardware
QUICK START GUIDE
when displayed on screen.
TWR-1
1
Advertisement
Table of Contents
Related Manuals for Gallagher TWR-1
Summary of Contents for Gallagher TWR-1
-
Page 1: Table Of Contents
Gallagher TWR-1 Weigh Scale Quick Start Guide TWR-1 QUICK START GUIDE Thank you for purchasing the Gallagher TWR-1 Weigh Scale unit. The Gallagher range of weighing systems is simple, tough, innovative and reliable. BONUS OFFER Register your product online at www.gallagherams.com to extend your warranty to two years for free. -
Page 2: Charging The Battery
Important: If the TWR-1 is to be stored for an extended period, this should be in a cool dry place with a fully charged battery. Connect the power adapter at the base of the unit and plug the TWR-1 into a power outlet and switch ON. -
Page 3: Understanding The Twr-1 Weighing Unit
Gallagher TWR-1 Weigh Scale Quick Start Guide UNDERSTANDING THE TWR-1 WEIGHING UNIT Find animal Remove animal On-screen Help Look up and add animal to Touch to display a session information about the current screen Weigh screen Touch Screen Tap the screen icons, field names or buttons to view or enter data. -
Page 4: Installation
To mount the bracket on either a vertical or horizontal bar, use the ‘U’ bolts included with the unit. Important: It is not recommended to mount the TWR-1 bracket on the weighing crate or chute as interaction with the scale can impair weighing performance. - Page 5 Weights should be evenly distributed over the top of the weigh bars. Connect the loadbar cables to the base of the TWR-1. A beep will sound indicating a successful connection/ disconnection of the loadbars.
- Page 6 Gallagher TWR-1 Weigh Scale Quick Start Guide Installing the Antenna Panel The TWR-1 has an internal reader, that when connected to a Gallagher Antenna panel will capture the Electronic ID tag data. To weigh animals in a crush, you will need: •...
- Page 7 Gallagher TWR-1 Weigh Scale Quick Start Guide FIRST TIME START-UP The first time the TWR-1 is powered on, the First Time Start-Up screen will display. Tap the screen to update the language, time, date and weight fields as required and then tap Save.
-
Page 8: Connecting Equipment To The Twr-1
A pass-code of “0000” may be required to complete this connection. Refer to Bluetooth – Connect EID Reader in the TWR-1 On-screen Help or your EID Reader User Manual for further information on pairing the reader. -
Page 9: Start A Session
The New Session screen is displayed. Quick Start to open the Weigh screen with the scale default settings. Note: To set up and use templates, refer to the TWR-1 On-board Help. To customize the session: OPTIONS click on the button at the lower left of the screen. - Page 10 Gallagher TWR-1 Weigh Scale Quick Start Guide Notes: • When the weight locks, there will be a beep (if turned on in Settings) and a red light above the Weigh button displays briefly. • Other information, for example: Notes, can be entered once the weight has locked or an ID has been entered.
- Page 11 Gallagher TWR-1 Weigh Scale Quick Start Guide Session Options The Session Options menu is used to configure settings for the current session. From this screen, tap the required option to change the session name, turn drafting On or Off, change the weight lock mode and configure Advanced settings.
-
Page 12: View Animal Information
Gallagher TWR-1 Weigh Scale Quick Start Guide VIEW ANIMAL INFORMATION The information collected during a session can be viewed from the session’s Weigh screen. To view information about all the animals in the session; All Animals to view weight range of animals. -
Page 13: Care And Maintenance
Follow the instructions on the screen to complete the update. CONNECTING THE TWR-1 TO A COMPUTER In order to transfer data on or off the TWR-1, you need to establish a connection between the TWR-1 and a PC/laptop that has Animal Performance Software (APS) software installed. -
Page 14: Approvals And Standards
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Caution: Changes or modifications not expressly approved by Gallagher Group Limited could void the user’s authority to operate the equipment... - Page 15 - Sheep Auto Drafter Antenna Panel (G05714) The Bluetooth® word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc. and any use by Gallagher Group Limited is under license. Other trademarks and trade names are those of their respective owners.
- Page 16 Gallagher Private Bag 3026, Hamilton, New Zealand...
