Wi-Fi Extender KWM1000
(included with KS1000)
The KING WiFiMax creates your own private
and secure Wi-Fi network, just like you have in your home. When
in range of an available network, simply configure your WiFiMax to
connect to that network, and it will extend the internet access from
that network to your own private Wi-Fi network.
Omnidirectional Wi-Fi Antenna KS1000
(not included with KWM1000)
The KING Swift is an omnidirectional Wi-Fi antenna
that increases the range and performance of your
KING WiFiMax router and range extender. This
2.4GHz Wi-Fi antenna mounts to your roof, connects
to your KING WiFiMax via a single cable, and allows
your KING WiFiMax to connect to networks from
even farther away and still utilize its 5GHz network for
fastest speeds.
CONTENTS ................................................................................................. 2
CONNECTIONS .......................................................................................... 3
FIRST-TIME SETUP ................................................................................ 4-5
STANDARD OPERATION ....................................................................... 6-9
INSTALLATION ................................................................................... 10-11
TROUBLESHOOTING .............................................................................. 12
SPECIFICATIONS .................................................................................... 13
LIMITED WARRANTY .............................................................................. 14
WIRELESS REGULATORY INFORMATION ............................................ 15
SWIFT
CONTENTS
Page 1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for KING Swift KS1000
Summary of Contents for KING Swift KS1000
-
Page 1: Table Of Contents
KING WiFiMax router and range extender. This 2.4GHz Wi-Fi antenna mounts to your roof, connects to your KING WiFiMax via a single cable, and allows your KING WiFiMax to connect to networks from even farther away and still utilize its 5GHz network for fastest speeds. -
Page 2: Contents
Dipole Antenna Manual Power Supply NOTE: No tools are required to set up and use the KING WiFiMax (unless wall mounting the unit). There are key hole slots on the back to mount the unit to a wall. The user must determine where and how to best mount the unit to a wall (inside use only). -
Page 3: Connections
CONNECTIONS Place your KING WiFiMax on a stable surface (or wall mount). Make connections as shown. Attach included dipole antenna or cable from KING Swift to open port. Rotate antennas into vertical position (up and down). Connect to power. NOTE: You can use the keyhole slots on the back to wall mount the unit. -
Page 4: First-Time Setup
FIRST-TIME SETUP NOTE: If you have already completed first-time setup, go to page 6. WHICH NETWORK TO CHOOSE: Back to Settings KING_XXXXXX_5G is the 5GHz network and is faster than KING_XXXXXX which is the WiFi 2.4GHz network. “XXXXXX” will be a set of numbers and letters Choose a Network... - Page 5 Disable Auto System Settings KC1096 4. This screen should appear. Enter a custom Wi-Fi Name & Password for both your 2.4GHz and 5GHz networks. Tap “Save.” TIP: KING highly WiFi Settings English Exit recommends password WiFi Name & Password Internet Status protecting your name.
-
Page 6: Standard Operation
STANDARD OPERATION 1. Go to your phone, tablet or computer’s settings Back to Settings page and connect to the Wi-Fi Network with your customized network name. WiFi The example shown is “MyWiFiName_5G”. If your device cannot connect to your 5G Choose a Network... - Page 7 Channel & Bandwidth Transmit Power Wireless Repeating: Enable Enable Channel/Bandwidth 2.4 GHz High/5 GHz High Parental Control Repeating Mode: WISP Client+AP KING Falcon 2 Upstream WiFi Name: Advanced Settings Beamforming+ AP Mode Anti-interference Select your network Upstream WiFi Password: Enable Disable Auto...
- Page 8 This screen should appear. The router is scanning for networks. WiFi Settings English Exit WiFi Name & Password Internet Status Internet Settings Wireless Repeating: WiFi Settings WiFi Name & Password Wireless Repeating Channel & Bandwidth Transmit Power Enable Repeating Mode: Enable WISP Client+AP...
- Page 9 Wi-Fi network with your customized network name, as Rebooting... Please wait 100% you may lose connection during the router’s rebooting process. KC1130 KC1113 Congratulations, your KING WiFiMax is now extending your network! Page 9...
-
Page 10: Installation
• When determining locations, make sure the long cable will reach the KING WiFiMax when attached to the KING Swift cable. (KING Swift cable may go directly to prewire enclosure - see opposite page). • Do not locate the KING WiFiMax or KING Swift in a slide-out. - Page 11 IMPORTANT! The installer is responsible for determining and supplying the most appropriate fasteners to secure the bracket to the roof. All holes, fastener heads, and the entire perimeter of the bracket must be completely sealed and weatherproofed with roof-compatible sealant. If there was a prewire enclosure on the roof, you will find a preinstalled wall plate in the vehicle.
-
Page 12: Troubleshooting
I don’t see the Upstream WiFi name I want to extend in my list of networks. If a network is very far away or very weak, the KING WiFiMax may not be able to see it, or may not offer it as an option. Try scanning again for networks by clicking on the blue circular arrows. -
Page 13: Specifications
SPECIFICATIONS KING WiFiMax Power: Included 12v power supply, requiring 110V AC plug-in Wireless standards: IEEE802.11a/b/g/n/ac Supported Frequencies: 2.4GHz and 5GHz (dual-band) Security: WPA/WPA2-PSK Storage Environment: Temperature -40ºF to 158ºF KING Swift Radio Frequency Band: 2.4GHz Wireless Standards: IEEE802.11a/b/g/n Antenna: 3dBi roof-mounted omnidirectional antenna Height: 9.5”... -
Page 14: Limited Warranty
• Customer is not the original owner. In no event shall KING be liable for any indirect, incidental, or consequential damages from the sale or use of the product. This disclaimer applies both during and after the term of this warranty. -
Page 15: Wireless Regulatory Information
WIRELESS REGULATORY INFORMATION FCC Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. - Page 16 Simply better, by design. ™ 11200 Hampshire Avenue South, Bloomington, MN 55438 PH 952.922.6889 || FAX 952.922.8424 || kingconnect.com ©2018 KING 23180 Rev A All trademarks are the sole property of their respective owners.
