VTech VM3252 Quick Start Manual page 2

Overview - Parent unit
Zoom / Back
LCD ON/OFF
Microphone
LED lights
Arrow keys
MENU/SELECT
On/off
TALK
VOL -
VOL +
Speaker
Power jack
Stand
Overview - Baby unit
Microphone
Infrared LEDs Speaker
Camera
ON/OFF switch
Light sensor Power jack
POWER LED light
Wall mount holes
Sound sensitivity and sound activation
Sound sensitivity
With sound sensitivity setting, you can choose to hear sounds
from the baby unit all the time, or to hear sounds that exceed
a certain level. The default level Highest allows you to hear all
sounds (including background noises).
If you set the sound
sensitivity to a lower level
(e.g. Medium), you will only
hear sounds that exceed the
selected level. The baby unit
may not detect soft sounds,
and the parent unit speaker
may remain quiet.
For details, please see Adjust
the sound sensitivity of
the baby unit in the User's
manual.
Night vision
The baby unit has infrared LEDs that
allow you to see your baby clearly at
night or in a dark room. When the baby
unit being viewed detects low light
levels, the infrared LEDs are switched
on automatically. The images from the
baby unit are in black and white, and
appears on the screen.
Notes
• It is normal if you see a short white glare
on your parent unit screen as the baby unit
is adapting to the dark environment.
• When the infrared LEDs are on, the images
are in black and white. This is normal.
Tip
• Depending on the surroundings and other
interfering factors, like lightings, objects,
colors and backgrounds, the display
resolution may vary. Adjust the baby unit's
angle or place the baby unit at a higher
level to prevent glare and blurry display.
Sound activation
When sound activation is on, the parent unit screen stays off to save
power when the baby unit detects no sound.
Once the baby unit detects sounds that are louder than the chosen
sound sensitivity level, the parent unit screen turns on automatically.
It will then turn off again after 50 seconds of no sound detection.
Dim mode
The dim mode is to help you save the parent unit power. Your parent unit display will dim
automatically after 10 minutes of inactivity, in which there is neither key pressed nor alert
received from the baby unit.
10 min inactivity
Press any buttons
Note
NOTE NOTES
• While the screen is dimmed, any keypress or alert message will trigger the screen to return to
the preset brightness level. After 10 minutes of inactivity, it will resume to dim mode.
Mount the baby unit on dry wall (optional)
Items to purchase
You will need to purchase the following
items separately to mount your baby unit:
2 screws 2 anchors
Note
NOTES NOTE
• The types of screws and anchors you need
depend on the composition of the wall.
Insert the screws into the holes and
tighten the screws until only 1/4 inch
of the screws are exposed.
NOTE NOTES Note
• Check for reception strength and camera
angle before drilling the holes.
Use a pencil to mark two holes in parallel.
Make sure they are the same distance apart
as the wall mount holes on the baby unit.
Align the wall mount holes on the
baby unit with the screws on the wall.
Slide the baby unit down until it locks
into place.
Drill two holes in the wall. If you drill the holes
into a stud, go to step 3.
-OR-
If you drill the holes into an object other than
a stud, insert the wall anchors into the holes.
Tap gently on the ends with a hammer until
Adjust the camera angle.
the wall anchors are flush with the wall.
For VM3252-2 only
Status check - Two baby units
If you are viewing baby unit , the POWER LED light of baby unit turns on.
As baby unit is not being viewed, its POWER LED light flashes.
Note
NOTE NOTES
• If you power on only one baby unit, your parent unit may display and the LINK LED light flashes.
Press to switch to the baby unit you have powered on.
Change different views - Patrol
Press MENU when the parent unit is idle. Press or to choose , then press SELECT or .
Press or to choose , then press SELECT to confirm your selection.
10s
Change different views - Single-cam
Press to switch to another camera in SINGLE-CAM mode.
Press .
