Page 1
Installation Manual ANTENNA EXTENSION KIT ENGLISH EXTANT-US-40-IA-en-11 | Version 1.1...
Page 2
Readers are cautioned, however, that product improvements and field usage experience may cause SMA Solar Technology America LLC and/or SMA Solar Technology Canada Inc. to make changes to these specifications without advance notice, or per contract provisions in those cases where a supply agreement requires advance notice.
Page 3
A warning describes a hazard to equipment or personnel. It calls attention to a procedure or practice, which, if not correctly performed or adhered to, could result in damage to or destruction of part or all of the SMA equipment and/ or other equipment connected to the SMA equipment or personal injury.
Page 4
Important Safety Instructions SMA Solar Technology America LLC Symbol Description CAUTION indicates a hazardous situation which, if not avoided, could result in minor or moderate injury. NOTICE is used to address practices not related to personal injury. EXTANT-US-40-IA-en-11 Installation Manual...
Page 5
All installations must conform with the laws, regulations, codes and standards applicable in the jurisdiction of installation. SMA assumes no responsibility for the compliance or non-compliance with such laws or codes in connection with the installation of the product.
Table of Contents SMA Solar Technology America LLC Table of Contents Information on this Document ..................... Validity ................................7 Target group ..............................7 Symbols................................7 Typographies ..............................7 Nomenclature ..............................8 Safety............................. Intended Use..............................9 Safety Information ............................9 Supported Products ............................10 Scope of Delivery .........................
SMA Solar Technology America LLC 1 Information on this Document Validity This document is valid for the Antenna Extension Kit (Product “EXTANT-US-40”). You can find the latest version of this document at www.SMA-Solar.com. Target group The tasks described in this document must only be performed by qualified persons. Qualified persons must have the following skills: •...
1 Information on this Document SMA Solar Technology America LLC Nomenclature Complete designation Designation in this document SMA Solar Technology America LLC SMA Solar Technology Canada Inc. Antenna Extension Kit Antenna, product PV system PV system EXTANT-US-40-IA-en-11 Installation Manual...
SMA Solar Technology America LLC 2 Safety Intended Use The Antenna Extension Kit is an accessory set for one SMA inverter and optimizes the SMA inverter’s WLAN radio range. The inverter still complies with the standard after the product has been installed.
• Ensure that no cables used for electrical connection are damaged. Supported Products The Antenna Extension Kit must only be installed in the following SMA inverters: • SB3.0-1SP-US-40 (Sunny Boy 3.0-US) • SB3.8-1SP-US-40 (Sunny Boy 3.8-US) •...
3 Scope of Delivery SMA Solar Technology America LLC 3 Scope of Delivery Check the scope of delivery for completeness and any externally visible damage. Contact your distributor if the scope of delivery is incomplete or damaged. Figure 1: Components included in the scope of delivery...
4 Mounting SMA Solar Technology America LLC 4 Mounting Mounting Position and Cable Route Figure 2: Mounting position and cable route in the inverter with the lower enclosure lid open Position Designation Communication assembly Pin connector ANT. for connecting the antenna cable...
4 Mounting SMA Solar Technology America LLC The mounting location of the antenna is crucial for the quality of the wireless connection. Radio waves are emitted in circles from the longitudinal side of the antenna. A circular dead spot begins at the tip of the antenna. If you place the receiver in this dead spot, the receiver cannot receive any radio waves from the antenna.
Page 14
4 Mounting SMA Solar Technology America LLC Procedure: Danger to life due to high voltages of the PV array When exposed to sunlight, the PV array generates dangerous direct voltage. Touching the DC conductors can lead to lethal electric shocks. Even if the DC load-break switch of the inverter is in the O, position, there will be dangerous direct voltage present in the DC conductors and on the DC-in connecting terminal plate in the Connection Unit of the inverter.
Page 15
4 Mounting SMA Solar Technology America LLC • Press the multi-hole seal out of the cable gland from the inside. • Route the antenna cable with the cable end with the plug through the swivel nut and the desired hole of the multi- hole seal.
Page 16
4 Mounting SMA Solar Technology America LLC • Lead the antenna cable plug from the antenna bracket’s slot. In doing so, make sure that the washer and the counter nut are on the outside of the antenna bracket and that the antenna cable is not kinked or twisted.
If the value External Antenna is not set, set the antenna type (see inverter user manual). • Ensure that the antenna of type “EXTANT-US-40” is installed correctly and that only the supplied antenna cable was used. • Ensure that the receiver is not placed in the dead spot (see Section 4.1 "Mounting Position and Cable Route", page 12).
6 Decommissioning SMA Solar Technology America LLC 6 Decommissioning Removing the Antenna Required tools: ☐ Long-nosed pliers Procedure: Danger to life due to high voltages of the PV array When exposed to sunlight, the PV array generates dangerous direct voltage. Touching the DC conductors can lead to lethal electric shocks.
7 Contact SMA Solar Technology America LLC 7 Contact If you have technical problems with our products, please contact the SMA Service Line. We require the following information in order to provide you with the necessary assistance: • Inverters: – Serial number –...
