Page 1: Quick Start Guide
Quick Start Guide AX17 Atlas 17” Quad 3G-SDI/HDMI 4K Monitor What’s Included 1x AX17 Monitor 1x Power Cable 1x Light Stand Mount 1x Rack Mount Set because we’re filmmakers too www.ikancorp.com | 1.713.272.8822 | sales@ikancorp.com... -
Page 2: Getting Started
Getting Started Tally Lights HDMI Input Switch Function Buttons* Menu Wheel/Button* SDI Input Switch On/Off Button 3.5mm Headphone Output Button Notes F1 - F5 Buttons: Functions can be mapped in the menu. Menu Wheel/Button: Press to opens the menu options. because we’re filmmakers too www.ikancorp.com | 1.713.272.8822 | sales@ikancorp.com... - Page 3 Configuration of Setting Menus Display Settings Brightness – 0-100 Contrast – 0-100 Saturation – 0-100 Hue – 0-100 Sharpness – 0 ; 2 ; 4 Backlight – 0-100 Color Temp – 9300K, 7500K, 6500K, 58000K, sRGB, User (Custom) Gamma – Off, 1.8, 2.0, 2.2, 2.4 Functions Center Mark –...
-
Page 4: Rack Mount Installation
Rack Mount Installation Light Stand Mount Installation because we’re filmmakers too www.ikancorp.com | 1.713.272.8822 | sales@ikancorp.com... -
Page 5: Specifications
1920x1080i @ 50, 59.94, 60 Hz 1920x1080psf @ 24, 25, 29.97, 30 Hz 1920x1080p @ 23.93, 24, 25, 29.97, 30, 50, 59.94, 60 Hz Optional Accessories Some other products that work well with the AX17 available from Ikan include: IB-HDL98S 98Wh Professional Battery (V-Mount) C-2KIT-98S Dual Charger and 2x 98Wh Battery Kit (V-Mount) because we’re filmmakers too... - Page 6 Damage caused by abuse or misuse, dismantling, or changes to the product not made by the company. • Damage caused by natural disaster, abnormal voltage, and environmental factors, etc. ©2018 Ikan Corporation. All rights reserved because we’re filmmakers too www.ikancorp.com | 1.713.272.8822 | sales@ikancorp.com...
